Description
Processor number of cores supported : 14, 6, 10, 16, 8, 12, 18
Compatible processor series : Intel® Core™ X-series
Processor socket : LGA 2066 (Socket R4)
Processor manufacturer : Intel
Parallel processing technology support : 4-Way CrossFireX, 4-Way SLI
Audio output channels : 7.1 channels
Component for : Workstation
Motherboard form factor : CEB
Motherboard chipset : Intel® X299
Harmonized System (HS) code : 84733020
Motherboard chipset family : Intel
Unbuffered memory : Yes
Supported memory clock speeds : 4133, 4000, 2933, 3600, 2666, 4266, 4200, 2400
Number of memory slots : 4
Supported memory types : DDR4-SDRAM
Maximum internal memory : 256 GB
Storage relative humidity (H-H) : 20 – 90%
Operating temperature (T-T) : 10 – 35 °C
Storage temperature (T-T) : -40 – 70 °C
Height : 287 mm
Width : 305 mm
Depth : 267 mm
LAN controller : Intel I225-LM
Ethernet interface type : 2.5 Gigabit Ethernet
Wi-Fi : No
Ethernet LAN : Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors : 1
Number of COM connectors : 1
EPS power connector (8-pin) : Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors : 1
ATX Power connector (24-pin) : Yes
Number of chassis fan connectors : 2
Number of SATA III connectors : 8
TPM connector : Yes
CPU fan connector : Yes
Clear CMOS button : Yes
Cables included : SATA
RAID levels : 5, 0, 1, 10
Supported storage drive interfaces : SATA
RAID support : Yes
Ethernet LAN (RJ-45) ports : 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity : 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 6
USB 2.0 ports quantity : 4
Headphone outputs : 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity : 1
Number of M.2 (M) slots : 2
PCI Express x16 (Gen 3.x) slots : 7
Trusted Platform Module (TPM) : Yes
Weight : 2.3 kg
Number of DIMM slots : 8
Number of processors supported : 1
