Description
Compatible processor series : 3rd Generation AMD Ryzen™ 3, 2nd Generation AMD Ryzen™ 5, 2nd Generation AMD Ryzen™ 3, 3rd Generation AMD Ryzen 5, 2nd Generation AMD Ryzen™ 7, 3rd Generation AMD Ryzen™ 9, 3rd Generation AMD Ryzen™ 7
Processor socket : Socket AM4
Processor manufacturer : AMD
Parallel processing technology support : 3-Way CrossFireX, 2-Way SLI
Number of displays supported : 2
On-board graphics card : Yes
Audio output channels : 8.0 channels
Cooling type : Active
Audio chip : Realtek ALC S1200A
Motherboard chipset family : AMD
Motherboard chipset : AMD X570
Component for : PC
Motherboard form factor : ATX
Power source type : ATX
Windows operating systems supported : Windows 10
Number of mounting holes : 9
Harmonized System (HS) code : 84733020
Unbuffered memory : Yes
Maximum internal memory : 128 GB
Memory channels : Dual-channel
ECC : Yes
Number of memory slots : 4
Memory slots type : DIMM
Supported memory types : DDR4-SDRAM
Depth : 244 mm
Height : 77 mm
Width : 305 mm
LAN controller : Intel® I211-AT, Realtek RTL8117
Ethernet LAN : Yes
Wi-Fi : No
Ethernet interface type : Gigabit Ethernet
CPU fan connector : Yes
Number of SATA III connectors : 4
Peripheral (Molex) power connectors (4-pin) : 1
ATX Power connector (24-pin) : Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors : 2
Front panel audio connector : Yes
S/PDIF out connector : Yes
USB 2.0 connectors : 2
Number of chassis fan connectors : 3
EPS power connector (8-pin) : Yes
Front panel connector : Yes
BIOS memory size : 256 Mbit
BIOS type : UEFI AMI
System Management BIOS (SMBIOS) version : 3.2
ACPI version : 6.0
Supported storage drive types : HDD & SSD
Supported storage drive interfaces : M.2, PCI Express 3.0, SATA III
RAID levels : 1, 0, 10
Number of HDDs supported : 6
Ethernet LAN (RJ-45) ports : 2
DisplayPort version : 1.2
DisplayPorts quantity : 1
S/PDIF out port : Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity : 4
HDMI version : 1.4b
Microphone in : Yes
Headphone outputs : 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity : 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 2
HDMI ports quantity : 1
PCI Express x16 slots : 2
Number of M.2 (M) slots : 1
PCI Express x1 slots : 1
PCI Express x8 slots : 1
Weight : 1 kg
Analog audio output : 1
Number of Ultra M.2 (M) slots : 1
S/PDIF in port : Yes
