Description
Processor number of cores supported : 28
Processor socket : LGA 2066 (Socket R4)
Processor manufacturer : Intel
Parallel processing technology support : 3-Way SLI, 3-Way CrossFireX
Motherboard chipset : Intel® C422
Motherboard form factor : ATX
Audio output channels : 8.1 channels
Audio chip : Realtek ALC S1220A
Harmonized System (HS) code : 84733020
Supported memory clock speeds : 2666, 2133, 2400
Maximum internal memory : 512 GB
Memory channels : Quad-channel
Supported memory types : DDR4-SDRAM
Memory slots type : DIMM
Number of memory slots : 8
Width : 305 mm
Depth : 244 mm
LAN controller : Intel® I210-AT
Ethernet LAN : Yes
Wi-Fi : No
Ethernet interface type : Gigabit Ethernet
USB 3.2 Gen 1 (3.1 Gen 1) connectors : 1
Thunderbolt headers : 1
Number of SATA III connectors : 6
Number of COM connectors : 1
CPU fan connector : Yes
Number of chassis fan connectors : 2
Number of EATX power connectors : 1
USB 2.0 connectors : 1
USB 3.2 Gen 2 (3.1 Gen 2) connectors : 1
BIOS type : UEFI
Clear CMOS button : Yes
Package weight : 7.49 kg
Supported storage drive interfaces : SATA III
RAID levels : 0, 10, 1
RAID support : Yes
USB 2.0 ports quantity : 4
Ethernet LAN (RJ-45) ports : 2
S/PDIF out port : Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity : 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity : 1
Microphone in : Yes
Number of M.2 (M) slots : 2
PCI Express x16 (Gen 3.x) slots : 2
PCI Express x16 (Gen 3.x) @ dual x8/x8 mode slots : 1
Number of processors supported : 3
Weight : 4.86 kg
PCI Express x16 dual x8/x8 mode : Yes
Audio output : Yes
Number of DIMM slots : 8
PCI Express x4 (Gen 3.x) slots : 1
