Description
System bus rate : 10.4 GT/s
Processor manufacturer : Intel
On-board graphics card model : Aspeed AST2500
On-board graphics card memory : 64 MB
Parallel processing technology support : Not supported
Discrete graphics support : Yes
Harmonized System (HS) code : 84733020
Motherboard form factor : ATX
Motherboard chipset : Intel® C621
Component for : Server
Maximum internal memory : 1.54 TB
Memory channels : Hexa-channel
Supported memory types : DDR4-SDRAM
Supported memory clock speeds : 2666, 2400
Maximum RDIMM memory : 384 GB
Operating temperature (T-T) : 10 – 35 °C
Storage temperature (T-T) : -40 – 70 °C
Storage relative humidity (H-H) : 20 – 90%
Width : 305 mm
LAN controller : Intel® I210-AT
Ethernet LAN : Yes
Wi-Fi : No
Serial port headers : 1
Integrated SAS ports : 2
Power fan connector : Yes
TPM connector : Yes
ATX Power connector (24-pin) : Yes
EPS power connector (8-pin) : Yes
Number of SATA III connectors : 13
Package weight : 1.62 kg
RAID levels : 10, 1, 5, 0
Supported storage drive interfaces : Serial Attached SCSI (SAS)
RAID support : Yes
Ethernet LAN (RJ-45) ports : 3
VGA (D-Sub) ports quantity : 1
PCI Express x16 (Gen 3.x) slots : 2
Supported RDIMM module capacity : 8GB, 32GB, 4GB, 16GB
Supported DIMM module capacities : 32GB, 4GB, 16GB, 8GB, 64GB
Supported LRDIMM module capacity : 64GB, 32GB
Maximum UDIMM memory : 768 GB
Number of DIMM slots : 12
Supported RDIMM clock speeds : 2400, 2666 MHz
Weight : 970 g
Number of processors supported : 1
PCI Express x8 (Gen 3.x) slots : 2
Supported LRDIMM clock speeds : 2400, 2666 MHz
