Intel Xeon 6315P processor 2.8 GHz 12 MB Tray

Description

Launch date : Q1’25
Memory speed (max) : 4800 MHz
Processor family : Intel® Xeon®
Processor cores : 4
Processor model : 6315P
Processor threads : 4
Processor codename : Raptor Lake
Processor boost frequency : 5.2 GHz
System bus rate : 16 GT/s
Processor manufacturer : Intel
Thermal Design Power (TDP) : 55 W
Performance cores : 4
Maximum number of DMI lanes : 8
Processor socket : LGA 1700
Processor base frequency : 2.8 GHz
Processor ARK ID : 241603
Processor operating modes : 64-bit
Processor cache : 12 MB
On-board graphics card model : Not available
Discrete graphics card model : Not available
Discrete graphics card : No
On-board graphics card : No
CPU configuration (max) : 1
PCI Express configurations : 1×16+1×4, 2×8+1×4
Thermal Monitoring Technologies : Yes
PCI Express slots version : 5.0
Embedded options available : No
Maximum number of PCI Express lanes : 20
Supported instruction sets : SSE4.1, SSE4.2, AVX 2.0
Execute Disable Bit : Yes
Scalability : 1S
Market segment : Server
Use conditions : Server/Enterprise
Idle States : Yes
Memory types supported by processor : DDR5-SDRAM
ECC : Yes
Maximum internal memory supported by processor : 128 GB
Memory clock speeds supported by processor : 4800 MHz
Memory channels : Dual-channel
Tjunction : 100 °C
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Enhanced Intel SpeedStep Technology : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : No
Intel® Turbo Boost Technology : 2.0
Intel Virtualization Technology (VT-x) : Yes
Intel® OS Guard : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel® Total Memory Encryption – Multi Key : Yes
Intel 64 : Yes
Mode-based Execute Control (MBE) : Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp) : Yes
Intel® Boot Guard : Yes
Microprocessor PCIe Revision : Gen 5
Intel® Secure Key : Yes
Intel Trusted Execution Technology : Yes
Intel® Optane™ DC Persistent Memory Supported : No
Intel® Turbo Boost Technology 2.0 frequency : 4.7 GHz
Intel® Total Memory Encryption : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel Turbo Boost Max Technology 3.0 : No
Intel® Transactional Synchronization Extensions : No
Intel® Turbo Boost Max Technology 3.0 frequency : 4.5 GHz
Maximum internal memory : 128 GB
