Intel Xeon Gold 6334 processor 3.6 GHz 18 MB

Description

Servicing status : Baseline Servicing
Number of UPI links : 3
Supported memory types : DDR4-SDRAM
Launch date : Q2’21
Status : Launched
Target market : Cloud Computing
Memory speed (max) : 3200 MHz
Processor lithography : 10 nm
System bus rate : 11.2 GT/s
Processor threads : 16
Processor cores : 8
Processor family : Intel® Xeon®
Processor boost frequency : 3.7 GHz
Processor series : Intel Xeon Gold 6000 Series
Processor codename : Ice Lake
Component for : Server/workstation
Processor model : 6334
Processor operating modes : 64-bit
Thermal Design Power (TDP) : 165 W
Processor manufacturer : Intel
Box : No
Cooler included : No
Processor socket : LGA 4189
Processor ARK ID : 215273
Processor cache : 18 MB
Processor base frequency : 3.6 GHz
Low priority core frequency : 3.4 GHz
High priority core frequency : 3.7 GHz
Low priority cores : 4
High priority cores : 4
Processor generation : 3rd Generation Intel® Xeon® Scalable
On-board graphics card model : Not available
Discrete graphics card model : Not available
Discrete graphics card : No
On-board graphics card : No
Maximum number of PCI Express lanes : 64
PCI Express slots version : 4.0
Execute Disable Bit : Yes
Supported instruction sets : AVX 2.0, SSE4.2, AVX-512, AVX
Market segment : Server
Scalability : 2S
Export Control Classification Number (ECCN) : 5A992CN3
Commodity Classification Automated Tracking System (CCATS) : G178966
Memory channels : Octa-channel
Memory types supported by processor : DDR4-SDRAM
ECC : Yes
Tcase : 69 °C
Processor package size : 77.5 x 56.5 mm
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Intel® Turbo Boost Technology : 2.0
Mode-based Execute Control (MBE) : Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel Software Guard Extensions (Intel SGX) : Yes
Intel 64 : Yes
Intel® Optane™ DC Persistent Memory Supported : Yes
AVX-512 Fused Multiply-Add (FMA) units : 2
Intel® Run Sure Technology : Yes
Intel® Resource Director Technology (Intel® RDT) : Yes
Intel Trusted Execution Technology : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel® Speed Shift Technology : Yes
Intel® Volume Management Device (VMD) : Yes
Intel® Crypto Acceleration : Yes
Intel® Platform Firmware Resilience Support : Yes
Maximum Enclave Size Support for Intel® SGX : 64 GB
Intel® Transactional Synchronization Extensions : Yes
Intel® Total Memory Encryption : Yes
Maximum internal memory : 6 TB
Harmonized System (HS) code : 85423119
Warnings : Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity., The product should be used in accordance with the manufacturer’s instructions to avoid damage.
