Intel Xeon Gold 6346 processor 3.1 GHz 36 MB Tray

Description

Supported memory types : DDR4-SDRAM
Memory speed (max) : 3200 MHz
Status : Launched
Number of UPI links : 3
Target market : Cloud Computing
Servicing status : Baseline Servicing
Launch date : Q2’21
Processor cores : 16
Processor manufacturer : Intel
Processor cache : 36 MB
Processor family : Intel® Xeon®
Component for : Server/workstation
Processor model : 6346
Processor operating modes : 64-bit
High priority core frequency : 3.2 GHz
Processor ARK ID : 212457
Processor lithography : 10 nm
System bus rate : 11.2 GT/s
Processor threads : 32
Thermal Design Power (TDP) : 205 W
Processor base frequency : 3.1 GHz
Cooler included : No
Low priority core frequency : 3 GHz
Processor socket : LGA 4189
Processor codename : Ice Lake
Processor boost frequency : 3.6 GHz
Low priority cores : 12
High priority cores : 4
Processor generation : 3rd Generation Intel® Xeon® Scalable
On-board graphics card model : Not available
On-board graphics card : No
Discrete graphics card : No
Discrete graphics card model : Not available
Supported instruction sets : AVX-512, SSE4.2, AVX 2.0, AVX
Export Control Classification Number (ECCN) : 5A992CN3
Market segment : Server
Scalability : 2S
Commodity Classification Automated Tracking System (CCATS) : G178966
Maximum number of PCI Express lanes : 64
Execute Disable Bit : Yes
PCI Express slots version : 4.0
Embedded options available : No
Memory types supported by processor : DDR4-SDRAM
Maximum internal memory supported by processor : 6.14 TB
ECC : Yes
Memory clock speeds supported by processor : 3200 MHz
Memory channels : Octa-channel
Tcase : 78 °C
Processor package size : 77.5 x 56.5 mm
Intel 64 : Yes
Intel Trusted Execution Technology : Yes
Intel® Turbo Boost Technology : 2.0
Intel Software Guard Extensions (Intel SGX) : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel® Volume Management Device (VMD) : Yes
Maximum Enclave Size Support for Intel® SGX : 64 GB
Intel® Optane™ Memory Ready : Yes
Intel® Total Memory Encryption : Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
Mode-based Execute Control (MBE) : Yes
Intel® Optane™ DC Persistent Memory Supported : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
AVX-512 Fused Multiply-Add (FMA) units : 2
Intel® Run Sure Technology : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel® Transactional Synchronization Extensions : Yes
Intel® Resource Director Technology (Intel® RDT) : Yes
Intel® Speed Shift Technology : Yes
Intel® Platform Firmware Resilience Support : Yes
Intel® Crypto Acceleration : Yes
Maximum internal memory : 6 TB
Harmonized System (HS) code : 85423119
Warnings : The product should be used in accordance with the manufacturer’s instructions to avoid damage., Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity.
