Description
Motherboard chipset : AMD B650
Processor socket : Socket AM5
Compatible processor series : AMD EPYC 4004, AMD Ryzen 5 8th Gen, AMD Ryzen 9 8th Gen, AMD Ryzen 9 9th Gen, AMD Ryzen 7 8th Gen, AMD Ryzen 3 8th Gen
Number of processors supported : 1
On-board graphics card model : Aspeed AST2600
PC health monitoring : Voltage, Fan, Temperature
Supported memory types : DDR5-SDRAM
Memory voltage : 1.1
Number of DIMM slots : 4
ECC : Yes
Supported RDIMM clock speeds : 3600 MHz
Non-ECC : Yes
Memory form factor : 288-pin DIMM
Hot-swap fan module : Yes
Number of fans : 6 fan(s)
Chassis type : Rack (1U)
Cooling type : Active
Product colour : Grey
LED indicators : Power, System, HDD, LAN
On/off switch : Yes
Reset button : Yes
Number of main power supplies : 2
Power supply : 650 W
80 PLUS certification : 80 PLUS Platinum
AC input voltage : 100 – 240 V
AC input frequency : 50/60 Hz
Operating temperature (T-T) : 10 – 35 °C
Storage temperature (T-T) : -40 – 70 °C
Storage relative humidity (H-H) : 20 – 90%
Height : 43.4 mm
Depth : 438 mm
Width : 676.5 mm
Ethernet interface type : Gigabit Ethernet
Ethernet LAN : Yes
LAN controller : Intel I210
Plug and Play : Yes
System Management BIOS (SMBIOS) version : 3.5
BIOS type : UEFI AMI
BIOS memory size : 256 Mbit
ACPI version : 6.4
PCI Express x16 (Gen 4.x) slots : 2
Number of 3.5" bays : 2
Hot-swap HDD bays : Yes
Supported storage drive types : HDD & SSD
Supported storage drive interfaces : M.2, Serial ATA III
COM ports quantity : 1
Ethernet LAN (RJ-45) ports : 2
DisplayPorts quantity : 1
HDMI ports quantity : 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 6
IPMI LAN (RJ-45) port : Yes
VGA (D-Sub) ports quantity : 1
Warnings : Do not throw into regular trash, product requires special disposal., The product may contain components that are harmful to health, use caution when handling., Do not disassemble the unit yourself.
