Description
Maximum number of SMP processors : 1
Compatible processor series : AMD Ryzen™ 5, AMD Ryzen™ 3
Processor socket : Socket AM5
Processor manufacturer : AMD
On-board graphics card model : Aspeed AST2600
PC health monitoring : Voltage, CPU, Fan
Motherboard chipset : AMD B650 Express
Motherboard form factor : micro ATX
Component for : Server
Motherboard chipset family : AMD
ECC сompatibility : ECC & Non-ECC
Supported memory clock speed (max) : 5200 MHz
Memory slots type : DIMM
Supported memory types : DDR5-SDRAM
Memory voltage : 1.1
Supported memory clock speeds : 5200, 3600
Number of memory slots : 4
Maximum internal memory : 32 GB
Operating temperature (T-T) : 10 – 35 °C
Operating relative humidity (H-H) : 20 – 90%
Storage temperature (T-T) : -40 – 70 °C
Width : 243.8 mm
Depth : 243.8 mm
Wi-Fi : No
Ethernet LAN : Yes
ATX Power connector (24-pin) : Yes
Number of COM connectors : 1
EPS power connector (8-pin) : Yes
TPM connector : Yes
Number of SATA III connectors : 4
ACPI version : 6.4
BIOS type : UEFI AMI
System Management BIOS (SMBIOS) version : 3.5
BIOS memory size : 256 Mbit
Supported storage drive interfaces : M.2, SATA III
RAID levels : 1, 10, 0
RAID support : Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 4
IPMI LAN (RJ-45) port : Yes
Ethernet LAN (RJ-45) ports : 2
VGA (D-Sub) ports quantity : 1
Serial ports quantity : 1
HDMI ports quantity : 1
PCI Express x4 (Gen 4.x) slots : 1
Warnings : Use only in a dry and well-ventilated area., Do not open or disassemble the motherboard., The motherboard may contain electronic components hazardous to health – avoid direct contact.
