Description
Processor socket : LGA 1700
Supported processor sockets : LGA 1700
Compatible processor series : Intel® Pentium® Gold, Intel® Xeon®, Intel Xeon E
Processor manufacturer : Intel
On-board graphics card model : Aspeed AST2600
Motherboard form factor : micro ATX
PC health monitoring : Fan, CPU
Motherboard chipset : Intel C266
Motherboard chipset family : Intel
Memory voltage : 1.1 V
Supported memory types : DDR5-SDRAM
Number of memory slots : 4
Maximum internal memory : 32 GB
Supported memory clock speed (max) : 4400 MHz
ECC сompatibility : ECC
Storage relative humidity (H-H) : 20 – 90%
Operating temperature (T-T) : 10 – 35 °C
Storage temperature (T-T) : -40 – 70 °C
Width : 244 mm
Depth : 244 mm
USB 2.0 connectors : 3
USB 3.2 Gen 1 (3.1 Gen 1) connectors : 2
ATX Power connector (24-pin) : Yes
Number of SATA III connectors : 8
Peripheral (Molex) power connectors (4-pin) : 1
TPM connector : Yes
BIOS memory size : 256 Mbit
System Management BIOS (SMBIOS) version : 2.8
ACPI version : 6.4
BIOS type : AMI
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 2
VGA (D-Sub) ports quantity : 1
Serial ports quantity : 1
Ethernet LAN (RJ-45) ports : 2
Number of M.2 (M) slots : 1
PCI Express x16 (Gen 5.x) slots : 1
PCI Express x1 (Gen 4.x) slots : 1
PCI Express OCuLink connectors (NVMe support) : 3
PCI Express x4 (Gen 4.x) slots : 1
