Asrock GENOA2D24G-2L+ motherboard AMD SoC Socket SP5

Description

Processor manufacturer : AMD
Compatible processor series : AMD EPYC
Processor socket : Socket SP5
Maximum number of SMP processors : 2
On-board graphics card memory : 512 MB
On-board graphics card model : Aspeed AST2600
Parallel processing technology support : Not supported
Component for : Server
PC health monitoring : Voltage, Fan, Temperature
Product colour : Grey, Green
Motherboard chipset family : AMD
Motherboard chipset : AMD SoC
Memory slots type : DIMM
Memory voltage : 1.1 V
Number of memory slots : 24
Supported memory types : DDR5-SDRAM
Supported memory clock speeds : 4800
Maximum internal memory : 12.3 TB
Memory slot pin count : 288
Operating relative humidity (H-H) : 20 – 90%
Operating temperature (T-T) : -40 – 70 °C
Storage temperature (T-T) : 10 – 35 °C
Depth : 350 mm
Width : 430 mm
Ethernet interface type : Gigabit Ethernet
Ethernet LAN : Yes
Wi-Fi : No
LAN controller : Intel® I350
Number of chassis fan connectors : 6
Front panel connector : Yes
Chassis intrusion connector : Yes
Number of COM connectors : 1
ATX Power connector (24-pin) : Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors : 2
ACPI version : 6.4
System Management BIOS (SMBIOS) version : 3.5
Clear CMOS button : Yes
BIOS type : UEFI AMI
Number of storage drives supported : 34
Number of HDDs supported : 32
Supported storage drive interfaces : SATA III
Supported storage drive types : HDD & SSD
IPMI LAN (RJ-45) port : Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 4
VGA (D-Sub) ports quantity : 1
Ethernet LAN (RJ-45) ports : 2
