Description
Processor socket : Socket SP3
Maximum number of SMP processors : 1
Compatible processor series : AMD EPYC 7003
Processor manufacturer : AMD
On-board graphics card memory : 512 MB
On-board graphics card model : Aspeed AST2500
Motherboard form factor : ATX
Motherboard chipset family : AMD
Component for : Server
Maximum RDIMM memory : 256 GB
Memory voltage : 1.2 V
Supported memory types : DDR4-SDRAM
Number of memory slots : 8
Memory slots type : DIMM
Operating temperature (T-T) : 10 – 35 °C
Operating relative humidity (H-H) : 20 – 90%
Storage temperature (T-T) : -40 – 70 °C
Depth : 244 mm
Width : 305 mm
Wi-Fi : No
Ethernet LAN : Yes
TPM connector : Yes
EPS power connector (8-pin) : Yes
ATX Power connector (24-pin) : Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors : 1
Number of SATA III connectors : 10
BIOS type : UEFI AMI
BIOS memory size : 32 Mbit
System Management BIOS (SMBIOS) version : 3.3.0
ACPI version : 6.3
Supported storage drive interfaces : M.2, SATA III
IPMI LAN (RJ-45) port : Yes
VGA (D-Sub) ports quantity : 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 2
Ethernet LAN (RJ-45) ports : 3
Serial ports quantity : 1
PCI Express x16 (Gen 4.x) slots : 7
Warnings : The motherboard may contain electronic components hazardous to health – avoid direct contact., Do not open or disassemble the motherboard., Use only in a dry and well-ventilated area.
