Description
Compatible processor series : Intel® Xeon®
Processor socket : LGA 4189
Maximum number of SMP processors : 1
Processor manufacturer : Intel
On-board graphics card model : Aspeed AST2500
On-board graphics card memory : 16 MB
Motherboard chipset family : Intel
PC health monitoring : Voltage, Temperature, Fan
Motherboard form factor : ATX
Component for : Server
Motherboard chipset : Intel C621A
Maximum RDIMM memory : 64 GB
Memory slots type : DIMM
Memory voltage : 1.2 V
Number of memory slots : 8
Supported memory types : DDR4-SDRAM
Operating relative humidity (H-H) : 20 – 90%
Operating temperature (T-T) : 10 – 35 °C
Storage temperature (T-T) : -40 – 70 °C
Width : 304.8 mm
Depth : 243.8 mm
Wi-Fi : No
Ethernet LAN : Yes
LAN controller : Intel I210, Realtek RTL8211E
Number of SATA III connectors : 13
USB 2.0 connectors : 1
ATX Power connector (24-pin) : Yes
TPM connector : Yes
EPS power connector (8-pin) : Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors : 1
BIOS memory size : 256 Mbit
BIOS type : UEFI AMI
RAID levels : 10, 5, 0, 1
Supported storage drive interfaces : M.2, SATA III
RAID support : Yes
VGA (D-Sub) ports quantity : 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 4
Ethernet LAN (RJ-45) ports : 3
IPMI LAN (RJ-45) port : Yes
PCI Express x16 (Gen 4.x) slots : 4
Warnings : Adjust adequate ventilation to avoid overheating and potential damage., The product contains electrical components – take care during installation to avoid injury., Avoid contact with liquids and moisture to prevent damage to equipment.
