Description
Processor socket : Socket sWRX8
Processor manufacturer : AMD
Compatible processor series : AMD Ryzen Threadripper 1000 Series
Maximum number of SMP processors : 1
On-board graphics card model : Aspeed AST2500
On-board graphics card memory : 512 MB
Motherboard chipset : AMD WRX80
Component for : Server
PC health monitoring : LED, CPU, Voltage, Fan
Motherboard form factor : ATX
Motherboard chipset family : AMD
ECC сompatibility : ECC & Non-ECC
Maximum RDIMM memory : 128 GB
Memory voltage : 1.2 V
Number of memory slots : 8
Supported memory types : DDR4-SDRAM
Memory slots type : DIMM
Operating relative humidity (H-H) : 20 – 90%
Operating temperature (T-T) : 10 – 35 °C
Storage temperature (T-T) : -40 – 70 °C
Depth : 244 mm
Width : 305 mm
LAN controller : Intel X710-AT2
Wi-Fi : No
Ethernet LAN : Yes
Number of SATA III connectors : 12
ATX Power connector (24-pin) : Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors : 1
TPM connector : Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors : 1
BIOS memory size : 256 Mbit
System Management BIOS (SMBIOS) version : 2.8
ACPI version : 2.0
BIOS type : AMI
Supported storage drive interfaces : M.2, SATA III
Ethernet LAN (RJ-45) ports : 3
IPMI LAN (RJ-45) port : Yes
Serial ports quantity : 1
VGA (D-Sub) ports quantity : 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 2
PCI Express x16 (Gen 4.x) slots : 7
Warnings : Do not open or disassemble the motherboard., The motherboard may contain electronic components hazardous to health – avoid direct contact., Use only in a dry and well-ventilated area.
