Description
Compatible processor series : Intel Xeon E, Intel® Pentium®
Processor manufacturer : Intel
Processor socket : LGA 1200 (Socket H5)
On-board graphics card memory : 64 MB
On-board graphics card model : Aspeed AST2600
Graphics card family : ASPEED
On-board graphics card : Yes
Motherboard form factor : ATX
PC health monitoring : Fan, CPU
Component for : Server
Motherboard chipset : Intel C256
Motherboard chipset family : Intel
Supported memory clock speeds : 2933, 3200, 2666
Supported memory module capacities : 32GB, 8GB, 16GB
Maximum internal memory : 128 GB
Number of memory slots : 4
Memory slots type : DIMM
Supported memory types : DDR4-SDRAM
Supported memory clock speed (max) : 3200 MHz
Storage temperature (T-T) : -40 – 70 °C
Operating temperature (T-T) : 10 – 50 °C
Storage relative humidity (H-H) : 20 – 90%
Width : 305 mm
Depth : 244 mm
Height : 68 mm
Ethernet LAN : Yes
Wi-Fi : No
Ethernet interface type : Gigabit Ethernet
USB 3.2 Gen 1 (3.1 Gen 1) connectors : 1
Power fan connector : Yes
Chassis intrusion connector : Yes
ATX Power connector (24-pin) : Yes
Number of COM connectors : 1
TPM connector : Yes
Number of SATA III connectors : 8
USB 2.0 connectors : 1
Package height : 78 mm
Package depth : 281 mm
Package weight : 1.5 kg
Package width : 341 mm
RAID support : Yes
Supported storage drive interfaces : M.2, SATA III
Supported storage drive types : HDD & SSD
Number of HDDs supported : 8
Number of storage drives supported : 10
PS/2 ports quantity : 1
Ethernet LAN (RJ-45) ports : 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity : 2
HDMI ports quantity : 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 2
VGA (D-Sub) ports quantity : 1
Number of M.2 (M) slots : 2
PCI Express x8 (Gen 3.x) slots : 2
PCI Express x16 (Gen 4.x) slots : 1
PCI Express x8 (Gen 4.x) slots : 1
Weight : 800 g
Harmonized System (HS) code : 84733020
Warnings : Avoid contact with liquids and moisture to prevent damage to equipment., The product contains electrical components – take care during installation to avoid injury., Adjust adequate ventilation to avoid overheating and potential damage.
