Description
Supported processor sockets : LGA 1700
Compatible processor series : Intel Xeon E, Intel® Pentium®, AMD Turion X2 Ultra Dual-Core, Intel Xeon 6300
Processor manufacturer : Intel
Processor socket : LGA 1700
Parallel processing technology support : Not supported
Component for : Server
Cooling type : Passive
Power source type : ATX
Motherboard chipset family : Intel
Product colour : Black
Motherboard chipset : Intel C266
Motherboard form factor : ATX
PC health monitoring : Fan, Temperature, CPU
Memory channels : Dual-channel
Supported memory clock speed (max) : 4400 MHz
Number of memory slots : 4
Memory slots type : DIMM
Supported memory types : DDR5-SDRAM
ECC сompatibility : ECC
Maximum internal memory per slot : 32 GB
Supported memory clock speeds : 4000, 3600, 4400 MHz
Maximum internal memory : 128 GB
Storage relative humidity (H-H) : 20 – 90%
Operating temperature (T-T) : 10 – 50 °C
Storage temperature (T-T) : -40 – 70 °C
Width : 305 mm
Depth : 244 mm
Height : 68 mm
Wi-Fi : No
Ethernet LAN : Yes
Ethernet interface type : Gigabit Ethernet
EPS power connector (8-pin) : Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors : 1
Number of COM connectors : 1
Number of chassis fan connectors : 6
ATX Power connector (24-pin) : Yes
Chassis intrusion connector : Yes
Front panel connector : Yes
TPM connector : Yes
12V power connector : Yes
Number of EPS power connectors (8-pin) : 1
USB 2.0 connectors : 1
Number of SATA III connectors : 8
USB 3.2 Gen 1 (3.1 Gen 1) connectors : 1
Package weight : 1.5 kg
Package width : 341 mm
Package height : 78 mm
Package depth : 281 mm
Number of storage drives supported : 10
Number of HDDs supported : 8
Supported storage drive types : HDD & SSD
Supported storage drive interfaces : PCI Express 4.0, SATA III
Ethernet LAN (RJ-45) ports : 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity : 4
USB 2.0 ports quantity : 2
VGA (D-Sub) ports quantity : 1
Number of M.2 (M) slots : 2
PCI Express x4 (Gen 4.x) slots : 2
PCI Express x16 (Gen 5.x) slots : 1
PCI Express x8 (Gen 5.x) slots : 1
2nd M.2 highest PCI Express generation : 4.0
2nd M.2 largest key size : 22110
1st M.2 highest PCI Express generation : 4.0
1st M.2 largest key size : 22110
Weight : 800 g
