Description
Processor manufacturer : Intel
Supported processor sockets : Intel LGA1851
Compatible processor series : Intel Core Ultra (Series 2)
Processor socket : LGA 1851 (Socket V1)
Maximum resolution : 3840 x 2160 pixels
Parallel processing technology support : Not supported
Motherboard chipset : Intel W880
Component for : Workstation
Motherboard form factor : ATX
Windows operating systems supported : Windows 11, Windows 10 x64
Audio output channels : 7.1 channels
Cooling type : Passive
Power source type : ATX
Audio chip : Realtek ALC1220P
Product colour : Grey
Motherboard chipset family : Intel
Maximum internal memory : 256 GB
Memory channels : Dual-channel
Unbuffered memory : Yes
Maximum internal memory per slot : 64 GB
ECC сompatibility : Non-ECC
Number of memory slots : 4
Memory slots type : DIMM
Supported memory types : DDR5-SDRAM
Supported memory clock speed (max) : 9066 MHz
Width : 305 mm
Depth : 244 mm
Ethernet interface type : Gigabit Ethernet, 2.5 Gigabit Ethernet
Ethernet LAN : Yes
Wi-Fi : No
Chassis intrusion connector : Yes
Number of chassis fan connectors : 5
ATX Power connector (24-pin) : Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors : 1
Front panel audio connector : Yes
EPS power connector (8-pin) : Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors : 1
Number of COM connectors : 1
Number of SATA III connectors : 4
USB 2.0 connectors : 2
Thunderbolt headers : 1
Front panel connector : Yes
CPU fan connector : Yes
Number of EPS power connectors (8-pin) : 2
Number of water pump connectors : 1
Number of CPU fan connectors : 1
Number of temperature sensor headers : 1
12V power connector : Yes
Integrated SAS ports : 1
BIOS type : UEFI AMI
Clear CMOS button : Yes
BIOS memory size : 256 Mbit
Cables included : SATA
RAID levels : 1, 10, 0, 5
Supported storage drive types : HDD & SSD
Supported storage drive interfaces : M.2, PCI Express 4.0, PCI Express 5.0, SATA III
Number of storage drives supported : 8
RAID support : Yes
Number of HDDs supported : 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 6
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity : 1
DisplayPort version : 2.1
HDMI ports quantity : 1
HDMI version : 2.1
Ethernet LAN (RJ-45) ports : 3
Thunderbolt ports quantity : 1
Line-in : Yes
Headphone outputs : 1
VGA (D-Sub) ports quantity : 1
Number of M.2 (M) slots : 4
1st M.2 highest PCI Express generation : 5.0
1st M.2 largest key size : 2280
2nd M.2 largest key size : 2280
4th M.2 highest PCI Express generation : 4.0
3rd M.2 largest key size : 2280
3rd M.2 highest PCI Express generation : 4.0
2nd M.2 highest PCI Express generation : 4.0
4th M.2 largest key size : 2280
PCI Express x16 (Gen 4.x) slots : 1
PCI Express x16 (Gen 5.x) slots : 2
