Description
Processor socket : LGA 2066 (Socket R4)
Maximum number of SMP processors : 1
Compatible processor series : Intel® Core™ X-series
Processor manufacturer : Intel
Parallel processing technology support : 3-Way SLI, 3-Way CrossFireX
Audio output channels : 7.1 channels
Power source type : ATX
Motherboard chipset : Intel® X299
Motherboard form factor : ATX
Component for : PC
Harmonized System (HS) code : 84733020
Audio chip : Realtek S1220A
Motherboard chipset family : Intel
Memory slots type : DIMM
Unbuffered memory : Yes
Supported memory clock speeds : 3600, 2666, 2133, 4000, 2400
Maximum internal memory : 128 GB
Number of memory slots : 8
Supported memory types : DDR4-SDRAM
Depth : 243.8 mm
Height : 291 mm
Width : 304.8 mm
Ethernet interface type : Gigabit Ethernet
Ethernet LAN : Yes
LAN controller : Intel® I211-AT
Thunderbolt headers : 1
ATX Power connector (24-pin) : Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors : 1
Number of EATX power connectors : 1
12V power connector : Yes
EPS power connector (8-pin) : Yes
USB 2.0 connectors : 1
Number of COM connectors : 1
Number of SATA III connectors : 6
Front panel connector : Yes
CPU fan connector : Yes
Clear CMOS button : Yes
Cables included : SATA
Manual : Yes
Drivers included : Yes
RAID levels : 0, 1, 10, 5
S/PDIF out port : Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity : 1
Ethernet LAN (RJ-45) ports : 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity : 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 4
USB 2.0 ports quantity : 4
PCI Express x16 (Gen 3.x) slots : 4
Number of M.2 (M) slots : 2
Intel Extreme Memory Profile (XMP) : Yes
PCI Express x4 (Gen 3.x) slots : 1
Weight : 2.29 kg
VGA connectors : 1
