Description
Processor socket : LGA 3647 (Socket P)
Processor manufacturer : Intel
Compatible processor series : Intel® Xeon Phi™
Graphics card : AST2500
Graphics card family : ASPEED
Maximum graphics card memory : 64 MB
On-board graphics card : Yes
PC health monitoring : Fan, CPU
Motherboard form factor : ATX
Motherboard chipset family : Intel
Power source type : ATX
Harmonized System (HS) code : 84733020
Cooling type : Active
Component for : PC
Supported memory clock speeds : 2400, 2666, 2933
Supported memory module capacities : 64GB, 16GB, 8GB, 32GB, 128GB, 4GB
Maximum internal memory : 1.54 TB
Memory slots type : DIMM
Memory channels : Single-channel
Number of memory slots : 12
Supported memory types : DDR4-SDRAM
Operating temperature (T-T) : 10 – 35 °C
Storage temperature (T-T) : -40 – 70 °C
Storage relative humidity (H-H) : 20 – 90%
Depth : 244 mm
Width : 305 mm
Ethernet LAN : Yes
Wi-Fi : No
Ethernet interface type : 10 Gigabit Ethernet
Number of SATA III connectors : 13
USB 3.2 Gen 1 (3.1 Gen 1) connectors : 1
ATX Power connector (24-pin) : Yes
Power fan connector : Yes
USB 2.0 connectors : 1
Peripheral (Molex) power connectors (4-pin) : 6
CPU fan connector : Yes
Supported storage drive types : HDD & SSD
Supported storage drive interfaces : SATA III
Ethernet LAN (RJ-45) ports : 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 2
VGA (D-Sub) ports quantity : 1
PCI Express x16 (Gen 3.x) slots : 1
Number of M.2 (M) slots : 1
PCI Express x16 (Gen 3.x) @ dual x8/x8 mode slots : 1
PCI Express x8 (Gen 3.x) slots : 2
PCI Express x16 dual x8/x8 mode : Yes
Ethernet LAN connectors : 2
