Description
Processor operating modes : 64-bit
Processor threads : 4
Processor model : C3538
Processor cache : 8 MB
Processor socket : BGA 1310
Thermal Design Power (TDP) : 15 W
Processor cache type : Smart Cache
Processor manufacturer : Intel
Conflict-Free processor : Yes
Tcase : 87 °C
Maximum internal memory supported by processor : 256 GB
PCI Express slots version : 3.0
CPU configuration (max) : 1
Processor package size : 34 x 28 mm
Processor codename : Denverton
Processor code : SR3L7
Processor boost frequency : 2.1 GHz
Stepping : B1
Processor lithography : 14 nm
Processor family : Intel Atom®
Processor frequency : 2.1 GHz
Processor cores : 4
Tjunction : 100 °C
Memory clock speed : 2133 MHz
Memory form factor : SO-DIMM
Internal memory : 8 GB
Internal memory type : DDR4
Flash memory : 4 MB
Memory slots : 2
Maximum RAM supported : 32 GB
Number of fans : 2 fan(s)
Display type : LCD
Chassis type : Tower
Fan diameter : 12 cm
Product colour : Black
Built-in display : Yes
Cooling type : Active
Power consumption (typical) : 66.9 W
Number of power supply units : 1
Power supply location : Built-in
Power supply unit (PSU) capacity : 250 W
Power consumption (HDD standby) : 37.2 W
AC input voltage : 100 – 240 V
Operating relative humidity (H-H) : 5 – 95%
Operating temperature (T-T) : 0 – 40 °C
Width : 293 mm
Height : 215.5 mm
Depth : 230 mm
Weight : 6.2 kg
Wi-Fi : No
Ethernet LAN : Yes
Link aggregation : Yes
Load balancing system : Yes
iSCSI support : Yes
Dynamic DNS (DDNS) : Yes
Ethernet LAN data rate supported (max) : 10000 Mbit/s
Jumbo frames support : Yes
Wake-on-LAN ready : Yes
Ethernet LAN data rates : 2500 Mbit/s, 10000 Mbit/s
Noise level : 22 dB
Browser supported : Internet Explore 11+, FireFox, Chrome, Safari, Microsoft Edge
Backup function : Yes
Snapshot : Yes
System log : Yes
Built-in iTunes server : Yes
Backup features : Cloud, iSCSI LUN
S.M.A.R.T. support : Yes
Access Control List (ACL) : Yes
Multilingual support : Yes
Built-in UPnP AV media server : Yes
Share folder access right management : Yes
Device class : Small & Medium Business
Web-based management : Yes
Type : NAS
Security algorithms : HTTPS, 256-bit AES, SSH, SSL/TLS
Cables included : AC, LAN (RJ-45)
Quick installation guide : Yes
Number of screws : 66
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel Secure Boot Technology version : 1.00
Maximum number of PCI Express lanes : 12
Intel® OS Guard : Yes
Intel Secure Key Technology version : 1.00
Intel Virtualization Technology (VT-x) : Yes
Intel® Secure Key : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Execute Disable Bit : Yes
Intel QuickAssist Technology : Yes
Memory types supported by processor : DDR4-SDRAM
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Embedded options available : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : No
Intel® Turbo Boost Technology : No
Intel Secure Boot : Yes
Windows operating systems supported : Windows 8, Windows XP, Windows 7, Windows Vista, Windows 10
Mac operating systems supported : Mac OS X 10.13 High Sierra, Mac OS X 10.7 Lion, Mac OS X 10.10 Yosemite, Mac OS X 10.12 Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.14 Mojave, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks, Mac OS X 10.15 Catalina, Mac OS X 10.8 Mountain Lion
Operating system installed : ADM
Server operating systems supported : Windows Server 2012, Windows Server 2008, Windows Server 2003
Linux operating systems supported : Yes
Operating system version : 3.1
Number of storage drives supported : 8
Storage drive sizes supported : 3.5", 2.5
Number of M.2 (M & B) slots : 2
Maximum supported storage capacity : 128 TB
Online RAID migration : Yes
Supported file systems : BTRFS, ext4, FAT32, exFAT, HFS+, ext3, NTFS
Storage drives installed : No
Total installed storage capacity : 0 TB
Storage drive capacity : 0 GB
Installed storage drive type : No
Supported storage drive types : HDD & SSD
RAID support : Yes
Supported storage drive interfaces : Serial ATA III
RAID levels : 0, 6, 1, JBOD, 5, 10
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 2
USB port : Yes
Ethernet LAN (RJ-45) ports : 4
Processor ARK ID : 97929
Harmonized System (HS) code : 84714100
