Description
CPU configuration (max) : 1
Processor family : Intel Atom®
Processor frequency : 2.1 GHz
Conflict-Free processor : Yes
Processor model : C3538
Processor manufacturer : Intel
Processor cores : 4
Maximum RAM supported : 128 GB
Internal memory type : DDR4
Flash memory : 8000 MB
Internal memory : 8 GB
Memory slots : 4
Memory form factor : SO-DIMM
Product colour : Black
LED indicators : Yes
Cooling type : Active
Chassis type : Rack (2U)
Fan diameter : 6 cm
Number of fans : 2 fan(s)
AC input voltage : 100-240 V
Power consumption (HDD standby) : 67 W
Power supply location : Built-in
Power consumption (typical) : 115 W
Redundant power supply (RPS) support : Yes
Number of power supply units : 2
Power supply unit (PSU) capacity : 350 W
Operating temperature (T-T) : 0 – 40 °C
Operating relative humidity (H-H) : 5 – 90%
Weight : 11.7 kg
Height : 88 mm
Depth : 535 mm
Width : 439 mm
Ethernet LAN data rates : 1000 Mbit/s, 2500 Mbit/s, 100
Wake-on-LAN ready : Yes
iSCSI support : Yes
Link aggregation : Yes
Ethernet LAN : Yes
Load balancing system : Yes
Dynamic DNS (DDNS) : Yes
Supported network protocols : CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP, TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog
Jumbo frames support : Yes
Security algorithms : 256-bit AES, SNMPv3, SNMP, HTTPS, WPA2-Enterprise, SNMPv2, WPA-Enterprise, SSL/TLS
Type : NAS
Web-based management : Yes
Browser supported : Firefox, Chrome, Safari, Microsoft Edge
Multilingual support : Yes
Access Control List (ACL) : Yes
Snapshot : Yes
Built-in UPnP AV media server : Yes
S.M.A.R.T. support : Yes
Device class : Small & Medium Business
Backup function : Yes
Backup features : Cloud, iSCSI LUN
System log : Yes
Power cables quantity : 1
Cables included : AC, LAN (RJ-45)
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Embedded options available : Yes
Intel Secure Boot : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Execute Disable Bit : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel Secure Boot Technology version : 1.00
Intel Secure Key Technology version : 1.00
Intel QuickAssist Technology : Yes
Server operating systems supported : Windows Server 2003, Windows Server 2016, Windows Server 2012, Windows Server 2008, Windows Server 2019
Windows operating systems supported : Yes
Operating system installed : ADM
Linux operating systems supported : Yes
RAID levels : 6, 5, JBOD, 10, 1, 0
RAID support : Yes
Supported storage drive interfaces : Serial ATA III
Supported storage drive types : HDD & SSD
Online RAID migration : Yes
Bad block scan : Yes
Total installed storage capacity : 0 TB
Supported file systems : BTRFS, exFAT, HFS+, ext4, FAT32, ext3, NTFS
Number of storage drives supported : 12
Storage drive capacity : 0 GB
Maximum supported storage capacity : 216 TB
Hot-swap drive bays : Yes
Storage drive sizes supported : 2.5, 3.5"
Storage drives installed : No
Installed storage drive type : No
PCI Express x8 (Gen 3.x) slots : 1
Ethernet LAN (RJ-45) ports : 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 4
USB port : Yes
Harmonized System (HS) code : 84714100
