Asustor Lockerstor 10 AS6510T NAS Tower Intel Atom® C3538 8 GB DDR4 0 TB ADM Black

Description

Processor operating modes : 64-bit
Processor cache type : Smart Cache
Processor manufacturer : Intel
Processor model : C3538
Conflict-Free processor : Yes
Tjunction : 100 °C
Processor cores : 4
Processor cache : 8 MB
Tcase : 87 °C
Processor threads : 4
Processor socket : BGA 1310
Thermal Design Power (TDP) : 15 W
Maximum internal memory supported by processor : 256 GB
Processor frequency : 2.1 GHz
PCI Express slots version : 3.0
Processor lithography : 14 nm
CPU configuration (max) : 1
Processor package size : 34 x 28 mm
Processor code : SR3L7
Stepping : B1
Processor codename : Denverton
Processor family : Intel Atom®
Memory form factor : SO-DIMM
Maximum RAM supported : 64 GB
Memory slots : 2
Memory clock speed : 2133 MHz
Internal memory : 8 GB
Flash memory : 4096 MB
Internal memory type : DDR4
Cooling type : Active
Fan diameter : 12 cm
Chassis type : Tower
Number of fans : 2 fan(s)
Display type : LCD
Built-in display : Yes
Product colour : Black
Redundant power supply (RPS) support : No
Power consumption (HDD standby) : 41.1 W
Power supply location : Built-in
Power consumption (typical) : 76.8 W
Number of power supply units : 1
Power supply unit (PSU) capacity : 250 W
AC input voltage : 100 – 240 V
Operating relative humidity (H-H) : 5 – 95%
Operating temperature (T-T) : 0 – 40 °C
Width : 293 mm
Height : 215.5 mm
Depth : 230 mm
Weight : 6.4 kg
iSCSI support : Yes
Load balancing system : Yes
Link aggregation : Yes
Ethernet LAN data rate supported (max) : 10000 Mbit/s
Dynamic DNS (DDNS) : Yes
DHCP server : Yes
WLAN adapter supported : Yes
Ethernet LAN : Yes
Jumbo frames support : Yes
Wake-on-LAN ready : Yes
Ethernet LAN data rates : 1000 Mbit/s, 100, 10000 Mbit/s, 2500 Mbit/s
Disk scan : Yes
Access Control List (ACL) : Yes
Multilingual support : Yes
Noise level (idle) : 22 dB
Backup features : iSCSI LUN, Cloud
Built-in UPnP AV media server : Yes
Browser supported : Internet Explore 11+, FireFox, Chrome, Safari, Microsoft Edge
System log : Yes
Number of users : 4096 user(s)
Universal Plug and Play (UPnP) : Yes
Backup function : Yes
Built-in iTunes server : Yes
S.M.A.R.T. support : Yes
Share folder access right management : Yes
Device class : Home & Home Office
Share folder : Windows ACL
Snapshot : Yes
Security algorithms : HTTPS, SSL/TLS, 256-bit AES, SSH
Web-based management : Yes
Type : NAS
Reset button : Yes
Cables included : LAN (RJ-45), AC
Number of screws : 66
Intel Secure Key Technology version : 1.00
Maximum number of PCI Express lanes : 12
Execute Disable Bit : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel Secure Boot Technology version : 1.00
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel® Secure Key : Yes
Memory types supported by processor : DDR4-SDRAM
Intel® OS Guard : Yes
Intel QuickAssist Technology : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : No
Embedded options available : Yes
Intel® Turbo Boost Technology : No
Intel Secure Boot : Yes
Operating system installed : ADM
Operating system version : 3.4
Mac operating systems supported : Mac OS X 10.8 Mountain Lion, Mac OS X 10.6 Snow Leopard, Mac OS X 10.9 Mavericks, Mac OS X 12.0 Monterey, Mac OS X 10.7 Lion, Mac OS X 11.0 Big Sur
Windows operating systems supported : Windows XP, Windows 7, Windows 8, Windows Vista, Windows 10
Server operating systems supported : Windows Server 2012, Windows Server 2008, Windows Server 2003
Other operating systems supported : Linux
Linux operating systems supported : Yes
Supported file systems : BTRFS, FAT32, exFAT, HFS+, ext4, ext3, NTFS
Number of storage drives supported : 10
Total installed storage capacity : 0 TB
Online RAID migration : Yes
Storage drives installed : No
Installed storage drive type : No
Storage drive capacity : 0 GB
Number of M.2 (M & B) slots : 2
Online RAID expansion : Yes
Bad block scan : Yes
Storage drive sizes supported : M.2, 2.5, 3.5"
Supported storage drive interfaces : Serial ATA III
RAID support : Yes
Supported storage drive types : HDD & SSD
RAID levels : 5, 10, 1, JBOD, 6, 0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 2
USB port : Yes
Ethernet LAN (RJ-45) ports : 4
Processor ARK ID : 97929
Harmonized System (HS) code : 84714100
