Description
Processor manufacturer : Intel
Processor frequency : 2 GHz
Processor family : Intel® Celeron®
Processor threads : 4
Processor cores : 4
Processor model : N5105
On-board graphics card model : Intel® UHD Graphics
Processor boost frequency : 2.9 GHz
CPU configuration (max) : 1
Flash memory : 8000 MB
Memory slots : 2
Internal memory type : DDR4
Internal memory : 8 GB
Memory form factor : SO-DIMM
Maximum RAM supported : 16 GB
Fan diameter : 12 cm
Number of fans : 1 fan(s)
Chassis type : Desktop
Cooling type : Active
Built-in display : Yes
Display type : LCD
Product colour : Black
Power consumption (sleep) : 0.81 W
Power supply unit (PSU) capacity : 250 W
Power consumption (HDD standby) : 27.7 W
Power supply location : External
Power consumption (typical) : 48.5 W
AC input voltage : 100 – 240 V
Operating temperature (T-T) : 0 – 40 °C
Operating relative humidity (H-H) : 5 – 95%
Depth : 230 mm
Width : 233 mm
Height : 185.5 mm
Weight : 4.4 kg
Jumbo frames support : Yes
Ethernet LAN : Yes
Wake-on-LAN ready : Yes
Ethernet LAN data rates : 100, 1000 Mbit/s, 2500 Mbit/s
Browser supported : Firefox, Chrome, Safari, Microsoft Edge
Type : NAS
Backup features : USB drive, iSCSI LUN, Cloud
Noise level : 18.1 dB
Backup function : Yes
Device class : Home & Home Office
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel 64 : Yes
Enhanced Intel SpeedStep Technology : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Idle States : Yes
Intel Trusted Execution Technology : No
Linux operating systems supported : Yes
Server operating systems supported : Windows Server 2012 Core, Windows Server 2003, Windows Server 2016, Windows Server 2022, Windows Server 2019, Windows Server 2008
Operating system installed : ADM
Mac operating systems supported : MacOS
Operating system version : 4.1
Windows operating systems supported : Yes
Storage drive sizes supported : 3.5", 2.5, M.2
RAID levels : 10, 1, 5, 0, 6, JBOD
Installed storage drive type : HDD
Number of M.2 (M & B) slots : 4
Storage drive interface : M.2, Serial ATA, Serial ATA II, Serial ATA III
Supported file systems : BTRFS, ext4, FAT32, exFAT, ext3, NTFS, HFS+
Number of storage drives supported : 6
Storage drives installed : Yes
Supported storage drive types : HDD & SSD
RAID support : Yes
USB port : Yes
HDMI version : 2.0b
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity : 2
HDMI ports quantity : 1
Ethernet LAN (RJ-45) ports : 2
Harmonized System (HS) code : 84714100
