Description
LED indicators : Link, Activity, Speed, System
Reset button : Yes
Product colour : White
Rack mounting : Yes
Power supply included : Yes
Power consumption (typical) : 5.7 W
Power source : AC
Power consumption (max) : 81.6 W
IGMP entries : 256
Access Control List (ACL) rules : 512
BPDU filtering/protection : Yes
IGMP snooping : Yes
SSH/SSL support : Yes
Access Control List (ACL) : Yes
Loop protection : Yes
Security algorithms : SSL/TLS
DHCP features : DHCP client
MAC address filtering : Yes
Operating temperature (T-T) : 0 – 50 °C
Operating relative humidity (H-H) : 10 – 90%
Heat dissipation : 273.43 BTU/h
Storage temperature (T-T) : -20 – 70 °C
Storage relative humidity (H-H) : 10 – 90%
Configuring Location Settings (CLI) : Yes
Switch layer : L2
Switch type : Managed
Quality of Service (QoS) support : Yes
MIB support : Y
Web-based management : Yes
System event log : Yes
Width : 279 mm
Depth : 170 mm
Height : 44 mm
Weight : 1.18 kg
Head-of-line (HOL) blocking : Yes
Networking standards : IEEE 802.1x, IEEE 802.3at, IEEE 802.3x, IEEE 802.3af, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.1w
Spanning tree protocol : Yes
Auto MDI/MDI-X : Yes
Broadcast storm control : Yes
Port mirroring : Yes
10G support : No
VLAN support : Yes
Number of VLANs : 256
Flow control support : Yes
Link aggregation : Yes
Flash memory : 64 MB
Internal memory : 256 MB
Firmware upgradeable : Yes
GARP VLAN Registration Protocol (GVRP) : Yes
Management protocols : SNMP
Basic switching RJ-45 Ethernet ports quantity : 8
Basic switching RJ-45 Ethernet ports type : Gigabit Ethernet (10/100/1000)
SFP module slots quantity : 2
Harmonized System (HS) code : 85176990
Forwarding rate : 14.88 Mpps
Jumbo frames : 9216
MAC address table : 8192 entries
Packet buffer memory : 4.1 MB
Switching capacity : 20 Gbit/s
Jumbo frames support : Yes
Power over Ethernet (PoE) ports quantity : 8
Power over Ethernet (PoE) : Yes
Total Power over Ethernet (PoE) budget : 65 W
Multicast support : Yes
Number of multicast groups filtered : 256
