Intel Xeon 4208 processor 2.1 GHz 11 MB Box, Tray

Description

Number of UPI links : 2
Supported memory types : DDR4-SDRAM
Status : Launched
Memory speed (max) : 2400 MHz
Launch date : Q2’19
Product type : Processor
Servicing status : Baseline Servicing
Processor ARK ID : 193390
Processor base frequency : 2.1 GHz
Processor manufacturer : Intel
Processor socket : LGA 3647 (Socket P)
Processor generation : 2nd Generation Intel® Xeon® Scalable
Cooler included : No
Thermal Design Power (TDP) : 85 W
Processor cache : 11 MB
Component for : Server/workstation
Processor lithography : 14 nm
Package type : Box, Tray
Processor boost frequency : 3.2 GHz
Processor threads : 16
Processor cores : 8
Processor model : 4208
Processor codename : Cascade Lake
Processor family : Intel Xeon Silver
Processor operating modes : 64-bit
Discrete graphics card : No
On-board graphics card : No
On-board graphics card model : Not available
Discrete graphics card model : Not available
PCI Express CEM revision : 3.0
Execute Disable Bit : Yes
Supported instruction sets : AVX-512, AVX, AVX 2.0, SSE4.2
Export Control Classification Number (ECCN) : 5A992C
Market segment : Server
Scalability : 2S
Commodity Classification Automated Tracking System (CCATS) : G077159
Embedded options available : No
PCI Express slots version : 3.0
Maximum number of PCI Express lanes : 48
Maximum internal memory supported by processor : 1.02 TB
Memory types supported by processor : DDR4-SDRAM
Memory channels : Hexa-channel
ECC : Yes
Memory clock speeds supported by processor : 2400 MHz
Tcase : 78 °C
Processor package size : 76mm x 56.5mm
Package height : 112 mm
Package width : 43 mm
Package weight : 201 g
Package depth : 137 mm
Intel VT-x with Extended Page Tables (EPT) : Yes
AVX-512 Fused Multiply-Add (FMA) units : 1
Intel TSX-NI : Yes
Intel® Speed Select technology – Performance Profile (Intel® SST-PP) : No
Intel 64 : Yes
Intel® Speed Shift Technology : Yes
Intel® Run Sure Technology : No
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
Intel® Resource Director Technology (Intel® RDT) : Yes
Intel Turbo Boost Max Technology 3.0 : No
Intel® Volume Management Device (VMD) : Yes
Intel® vPro™ Platform Eligibility : Yes
Intel Speed Select Technology (SST) : No
Intel® Transactional Synchronization Extensions : Yes
Intel® Optane™ DC Persistent Memory technology : No
Mode-based Execute Control (MBE) : Yes
Intel® Optane™ DC Persistent Memory Supported : No
Intel® Speed Select Technology – Base Frequency (Intel® SST-BF) : No
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Enhanced Intel SpeedStep Technology : Yes
Intel Trusted Execution Technology : Yes
Intel® Turbo Boost Technology : 2.0
Maximum internal memory : 1 TB
Harmonized System (HS) code : 85423119
Warnings : The product should be used in accordance with the manufacturer’s instructions to avoid damage., Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity.
