Intel Xeon E-2314 processor 2.8 GHz 8 MB Smart Cache Tray

Description

Status : Launched
Supported memory types : DDR4-SDRAM
Launch date : Q3’21
Servicing status : Baseline Servicing
Processor cache : 8 MB
Processor ARK ID : 212259
Processor operating modes : 64-bit
Processor cores : 4
Processor model : E-2314
Processor manufacturer : Intel
Cooler included : No
Processor base frequency : 2.8 GHz
Processor threads : 4
Processor cache type : Smart Cache
Thermal Design Power (TDP) : 65 W
Processor socket : LGA 1200 (Socket H5)
Component for : Server/workstation
System bus rate : 8 GT/s
Processor lithography : 14 nm
Processor boost frequency : 4.5 GHz
Processor family : Intel Xeon E
On-board graphics card : No
Discrete graphics card : No
On-board graphics card model : Not available
Discrete graphics card model : Not available
Market segment : Server
Idle States : Yes
Execute Disable Bit : Yes
Supported instruction sets : SSE4.1, AVX 2.0, AVX-512, SSE4.2
Export Control Classification Number (ECCN) : 5A992CN3
Maximum number of PCI Express lanes : 20
Scalability : 1S
Commodity Classification Automated Tracking System (CCATS) : G167599
PCI Express slots version : 4.0
PCI Express configurations : 1×8+3×4, 1×16+1×4, 2×8+1×4
Thermal Monitoring Technologies : Yes
CPU configuration (max) : 1
Memory types supported by processor : DDR4-SDRAM
ECC : Yes
Maximum internal memory supported by processor : 128 GB
Memory channels : Dual-channel
Tjunction : 100 °C
Processor package size : 37.5 x 37.5 mm
Intel Trusted Execution Technology : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel® OS Guard : Yes
Intel Software Guard Extensions (Intel SGX) : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel® Secure Key : Yes
Intel 64 : Yes
Intel® Boot Guard : Yes
Intel® vPro™ Platform Eligibility : Yes
Intel® Memory Protection Extensions (Intel® MPX) : Yes
Maximum Enclave Size Support for Intel® SGX : 0.5 GB
Intel® Transactional Synchronization Extensions : No
Intel® Turbo Boost Technology 2.0 frequency : 4.5 GHz
Intel® Optane™ DC Persistent Memory Supported : No
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : No
Intel® Turbo Boost Technology : 2.0
Enhanced Intel SpeedStep Technology : Yes
Maximum internal memory : 128 GB
Harmonized System (HS) code : 85423119
Warnings : Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity., The product should be used in accordance with the manufacturer’s instructions to avoid damage.
