Intel Xeon E-2324G processor 3.1 GHz 8 MB Smart Cache

Description

Status : Launched
Launch date : Q3’21
Servicing status : Baseline Servicing
Supported memory types : DDR4-SDRAM
Processor base frequency : 3.1 GHz
Cooler included : No
Box : No
Processor socket : LGA 1200 (Socket H5)
Processor threads : 4
Processor lithography : 14 nm
Processor manufacturer : Intel
System bus rate : 8 GT/s
Processor operating modes : 64-bit
Processor family : Intel Xeon E
Processor ARK ID : 212255
Processor cache : 8 MB
Thermal Design Power (TDP) : 65 W
Component for : Server/workstation
Processor boost frequency : 4.6 GHz
Processor cores : 4
Processor model : E-2324G
Processor cache type : Smart Cache
Maximum on-board graphics card memory : 64 GB
On-board graphics card dynamic frequency (max) : 1300 MHz
On-board graphics card refresh rate at maximum resolution (HDMI) : 60 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort) : 60 Hz
On-board graphics card refresh rate at maximum resolution (eDP – Integrated Flat Panel) : 60 Hz
On-board graphics card OpenGL version : 4.5
On-board graphics card 4K support : Yes
Number of execution units : 32
On-board graphics card : Yes
Discrete graphics card : No
On-board graphics card base frequency : 350 MHz
Discrete graphics card model : Not available
On-board graphics card model : Intel UHD Graphics P750
Export Control Classification Number (ECCN) : 5A992CN3
Commodity Classification Automated Tracking System (CCATS) : G167599
Supported instruction sets : SSE4.1, AVX 2.0, AVX-512, SSE4.2
Scalability : 1S
Market segment : Server
Idle States : Yes
PCI Express configurations : 1×16+1×4, 2×8+1×4, 1×8+3×4
CPU configuration (max) : 1
Execute Disable Bit : Yes
Thermal Monitoring Technologies : Yes
Maximum number of PCI Express lanes : 20
PCI Express slots version : 4.0
Memory types supported by processor : DDR4-SDRAM
Maximum internal memory supported by processor : 128 GB
ECC : Yes
Memory channels : Dual-channel
Tjunction : 100 °C
Processor package size : 37.5 x 37.5 mm
Intel® Turbo Boost Technology 2.0 frequency : 4.6 GHz
Intel® Transactional Synchronization Extensions : No
Maximum Enclave Size Support for Intel® SGX : 0.5 GB
Intel® Boot Guard : Yes
Intel Software Guard Extensions (Intel SGX) : Yes
Intel® Optane™ DC Persistent Memory Supported : No
Intel® vPro™ Platform Eligibility : Yes
Intel® Memory Protection Extensions (Intel® MPX) : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : No
Enhanced Intel SpeedStep Technology : Yes
Intel® InTru™ 3D Technology : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel® Quick Sync Video Technology : Yes
Intel® Turbo Boost Technology : 2.0
Intel 64 : Yes
Intel® OS Guard : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel Clear Video Technology : Yes
Intel® Clear Video HD Technology (Intel® CVT HD) : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel® Secure Key : Yes
Intel Trusted Execution Technology : Yes
Maximum internal memory : 128 GB
Harmonized System (HS) code : 85423119
Warnings : Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity., The product should be used in accordance with the manufacturer’s instructions to avoid damage.
