Intel Xeon E-2336 processor 2.9 GHz 12 MB Smart Cache Tray

Description

Supported memory types : DDR4-SDRAM
Launch date : Q3’21
Servicing status : Baseline Servicing
Status : Launched
Processor boost frequency : 4.8 GHz
Component for : Server/workstation
Processor cores : 6
Processor threads : 12
Thermal Design Power (TDP) : 65 W
Processor socket : LGA 1200 (Socket H5)
Processor operating modes : 64-bit
Processor family : Intel Xeon E
Processor cache : 12 MB
Processor base frequency : 2.9 GHz
Processor cache type : Smart Cache
System bus rate : 8 GT/s
Processor ARK ID : 212253
Processor lithography : 14 nm
Cooler included : No
Processor model : E-2336
Processor manufacturer : Intel
On-board graphics card : No
Discrete graphics card model : Not available
Discrete graphics card : No
PCI Express configurations : 1×16+1×4, 2×8+1×4, 1×8+3×4
CPU configuration (max) : 1
Idle States : Yes
Supported instruction sets : SSE4.1, AVX 2.0, AVX-512, SSE4.2
Export Control Classification Number (ECCN) : 5A992CN3
Maximum number of PCI Express lanes : 20
Scalability : 1S
Thermal Monitoring Technologies : Yes
Execute Disable Bit : Yes
Market segment : Server
PCI Express slots version : 4.0
Commodity Classification Automated Tracking System (CCATS) : G167599
Memory types supported by processor : DDR4-SDRAM
ECC : Yes
Maximum internal memory supported by processor : 128 GB
Memory channels : Dual-channel
Tjunction : 100 °C
Processor package size : 37.5 x 37.5 mm
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel Software Guard Extensions (Intel SGX) : Yes
Enhanced Intel SpeedStep Technology : Yes
Intel® Optane™ DC Persistent Memory Supported : No
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Intel® OS Guard : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel® Turbo Boost Technology 2.0 frequency : 4.8 GHz
Intel® Memory Protection Extensions (Intel® MPX) : Yes
Intel® Secure Key : Yes
Maximum Enclave Size Support for Intel® SGX : 0.5 GB
Intel® Turbo Boost Technology : 2.0
Intel® Transactional Synchronization Extensions : No
Intel® vPro™ Platform Eligibility : Yes
Intel® Boot Guard : Yes
Intel 64 : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel Trusted Execution Technology : Yes
Maximum internal memory : 128 GB
Harmonized System (HS) code : 85423119
Warnings : Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity., The product should be used in accordance with the manufacturer’s instructions to avoid damage.
