Intel Xeon E-2356G processor 3.2 GHz 12 MB Smart Cache Tray

Description

Status : Launched
Supported memory types : DDR4-SDRAM
Servicing status : Baseline Servicing
Launch date : Q3’21
Processor cache : 12 MB
Processor threads : 12
Processor cores : 6
Thermal Design Power (TDP) : 80 W
Processor operating modes : 64-bit
Processor socket : LGA 1200 (Socket H5)
Processor boost frequency : 5 GHz
Processor cache type : Smart Cache
Processor family : Intel Xeon E
Processor lithography : 14 nm
Component for : Server/workstation
Processor ARK ID : 212257
System bus rate : 8 GT/s
Processor manufacturer : Intel
Processor model : E-2356G
Cooler included : No
Processor base frequency : 3.2 GHz
On-board graphics card model : Intel UHD Graphics P750
Number of execution units : 32
Maximum on-board graphics card memory : 64 GB
On-board graphics card dynamic frequency (max) : 1300 MHz
Discrete graphics card : No
On-board graphics card base frequency : 350 MHz
On-board graphics card : Yes
Discrete graphics card model : Not available
On-board graphics card refresh rate at maximum resolution (HDMI) : 60 Hz
On-board graphics card refresh rate at maximum resolution (eDP – Integrated Flat Panel) : 60 Hz
On-board graphics card OpenGL version : 4.5
On-board graphics card refresh rate at maximum resolution (DisplayPort) : 60 Hz
On-board graphics card 4K support : Yes
CPU configuration (max) : 1
PCI Express configurations : 1×16+1×4, 2×8+1×4, 1×8+3×4
Execute Disable Bit : Yes
PCI Express slots version : 4.0
Idle States : Yes
Supported instruction sets : SSE4.1, AVX-512, SSE4.2, AVX 2.0
Thermal Monitoring Technologies : Yes
Maximum number of PCI Express lanes : 20
Scalability : 1S
Market segment : Server
Commodity Classification Automated Tracking System (CCATS) : G167599
Export Control Classification Number (ECCN) : 5A992CN3
Maximum internal memory supported by processor : 128 GB
Memory channels : Dual-channel
ECC : Yes
Memory types supported by processor : DDR4-SDRAM
Tjunction : 100 °C
Processor package size : 37.5 x 37.5 mm
Intel® Clear Video HD Technology (Intel® CVT HD) : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel® Quick Sync Video Technology : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Intel® Secure Key : Yes
Intel® InTru™ 3D Technology : Yes
Enhanced Intel SpeedStep Technology : Yes
Intel Clear Video Technology : Yes
Intel® Turbo Boost Technology : 2.0
Intel® OS Guard : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel Trusted Execution Technology : Yes
Intel 64 : Yes
Intel® vPro™ Platform Eligibility : Yes
Intel Software Guard Extensions (Intel SGX) : Yes
Intel® Boot Guard : Yes
Intel® Memory Protection Extensions (Intel® MPX) : Yes
Intel® Optane™ DC Persistent Memory Supported : No
Intel® Turbo Boost Technology 2.0 frequency : 5 GHz
Intel® Transactional Synchronization Extensions : No
Maximum Enclave Size Support for Intel® SGX : 0.5 GB
Maximum internal memory : 128 GB
Harmonized System (HS) code : 85423119
Warnings : The product should be used in accordance with the manufacturer’s instructions to avoid damage., Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity.
