Intel Xeon E-2374G processor 3.7 GHz 8 MB Smart Cache Tray

Description

Servicing status : Baseline Servicing
Launch date : Q3’21
Status : Launched
Supported memory types : DDR4-SDRAM
Processor base frequency : 3.7 GHz
Processor family : Intel Xeon E
Processor boost frequency : 5 GHz
Processor lithography : 14 nm
System bus rate : 8 GT/s
Processor cache type : Smart Cache
Processor operating modes : 64-bit
Processor cores : 4
Processor model : E-2374G
Processor threads : 8
Component for : Server/workstation
Processor manufacturer : Intel
Thermal Design Power (TDP) : 80 W
Processor socket : LGA 1200 (Socket H5)
Processor ARK ID : 212260
Processor cache : 8 MB
Cooler included : No
Number of execution units : 32
Discrete graphics card model : Not available
On-board graphics card model : Intel UHD Graphics P750
On-board graphics card refresh rate at maximum resolution (eDP – Integrated Flat Panel) : 60 Hz
On-board graphics card dynamic frequency (max) : 1300 MHz
Discrete graphics card : No
On-board graphics card refresh rate at maximum resolution (DisplayPort) : 60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI) : 60 Hz
Maximum on-board graphics card memory : 64 GB
On-board graphics card base frequency : 350 MHz
On-board graphics card OpenGL version : 4.5
On-board graphics card : Yes
On-board graphics card 4K support : Yes
Commodity Classification Automated Tracking System (CCATS) : G167599
Export Control Classification Number (ECCN) : 5A992CN3
CPU configuration (max) : 1
PCI Express slots version : 4.0
Thermal Monitoring Technologies : Yes
PCI Express configurations : 1×8+3×4, 1×16+1×4, 2×8+1×4
Maximum number of PCI Express lanes : 20
Idle States : Yes
Supported instruction sets : SSE4.2, SSE4.1, AVX-512, AVX 2.0
Scalability : 1S
Market segment : Server
Execute Disable Bit : Yes
Maximum internal memory supported by processor : 128 GB
Memory types supported by processor : DDR4-SDRAM
ECC : Yes
Memory channels : Dual-channel
Tjunction : 100 °C
Processor package size : 37.5 x 37.5 mm
Maximum Enclave Size Support for Intel® SGX : 0.5 GB
Intel® Turbo Boost Technology 2.0 frequency : 5 GHz
Intel® Transactional Synchronization Extensions : No
Enhanced Intel SpeedStep Technology : Yes
Intel® Turbo Boost Technology : 2.0
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Intel Clear Video Technology : Yes
Intel® Memory Protection Extensions (Intel® MPX) : Yes
Intel® Quick Sync Video Technology : Yes
Intel® InTru™ 3D Technology : Yes
Intel® Secure Key : Yes
Intel® Boot Guard : Yes
Intel® OS Guard : Yes
Intel 64 : Yes
Intel Trusted Execution Technology : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel® vPro™ Platform Eligibility : Yes
Intel® Optane™ DC Persistent Memory Supported : No
Intel Software Guard Extensions (Intel SGX) : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel® Clear Video HD Technology (Intel® CVT HD) : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Maximum internal memory : 128 GB
Harmonized System (HS) code : 85423119
Warnings : Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity., The product should be used in accordance with the manufacturer’s instructions to avoid damage.
