Intel Xeon E-2378G processor 2.8 GHz 16 MB Smart Cache Tray

Description

Supported memory types : DDR4-SDRAM
Launch date : Q3’21
Status : Launched
Servicing status : Baseline Servicing
Processor operating modes : 64-bit
Processor model : E-2378G
Processor cores : 8
Processor ARK ID : 212262
System bus rate : 8 GT/s
Processor socket : LGA 1200 (Socket H5)
Thermal Design Power (TDP) : 80 W
Processor cache type : Smart Cache
Processor threads : 16
Component for : Server/workstation
Processor manufacturer : Intel
Processor cache : 16 MB
Cooler included : No
Processor base frequency : 2.8 GHz
Processor boost frequency : 5.1 GHz
Processor family : Intel Xeon E
Processor lithography : 14 nm
Discrete graphics card : No
On-board graphics card base frequency : 350 MHz
On-board graphics card : Yes
Maximum on-board graphics card memory : 64 GB
On-board graphics card refresh rate at maximum resolution (eDP – Integrated Flat Panel) : 60 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort) : 60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI) : 60 Hz
On-board graphics card dynamic frequency (max) : 1300 MHz
On-board graphics card OpenGL version : 4.5
On-board graphics card 4K support : Yes
Discrete graphics card model : Not available
Number of execution units : 32
On-board graphics card model : Intel UHD Graphics P750
Maximum number of PCI Express lanes : 20
Supported instruction sets : AVX-512, AVX 2.0, SSE4.1, SSE4.2
Execute Disable Bit : Yes
Idle States : Yes
Export Control Classification Number (ECCN) : 5A992CN3
Scalability : 1S
Market segment : Server
Commodity Classification Automated Tracking System (CCATS) : G167599
PCI Express configurations : 1×16+1×4, 2×8+1×4, 1×8+3×4
CPU configuration (max) : 1
PCI Express slots version : 4.0
Thermal Monitoring Technologies : Yes
ECC : Yes
Memory channels : Dual-channel
Maximum internal memory supported by processor : 128 GB
Memory types supported by processor : DDR4-SDRAM
Tjunction : 100 °C
Processor package size : 37.5 x 37.5 mm
Intel® Quick Sync Video Technology : Yes
Intel® InTru™ 3D Technology : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel Clear Video Technology : Yes
Intel® Clear Video HD Technology (Intel® CVT HD) : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel Trusted Execution Technology : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel® Secure Key : Yes
Intel® OS Guard : Yes
Intel 64 : Yes
Intel® Transactional Synchronization Extensions : No
Intel® vPro™ Platform Eligibility : Yes
Intel® Boot Guard : Yes
Intel® Memory Protection Extensions (Intel® MPX) : Yes
Intel Software Guard Extensions (Intel SGX) : Yes
Intel® Optane™ DC Persistent Memory Supported : No
Maximum Enclave Size Support for Intel® SGX : 0.5 GB
Intel® Turbo Boost Technology 2.0 frequency : 5.1 GHz
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Enhanced Intel SpeedStep Technology : Yes
Intel® Turbo Boost Technology : 2.0
Maximum internal memory : 128 GB
Harmonized System (HS) code : 85423119
Warnings : Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity., The product should be used in accordance with the manufacturer’s instructions to avoid damage.
