Intel Xeon E-2386G processor 3.5 GHz 12 MB Smart Cache

Description

Servicing status : Baseline Servicing
Status : Launched
Supported memory types : DDR4-SDRAM
Launch date : Q3’21
Processor base frequency : 3.5 GHz
Processor boost frequency : 5.1 GHz
Processor lithography : 14 nm
Processor family : Intel Xeon E
Processor cache : 12 MB
Processor operating modes : 64-bit
System bus rate : 8 GT/s
Processor ARK ID : 214806
Processor threads : 12
Processor cache type : Smart Cache
Processor model : E-2386G
Processor cores : 6
Cooler included : No
Processor manufacturer : Intel
Box : No
Component for : Server/workstation
Processor socket : LGA 1200 (Socket H5)
Thermal Design Power (TDP) : 95 W
Number of execution units : 32
Discrete graphics card model : Not available
On-board graphics card : Yes
On-board graphics card refresh rate at maximum resolution (DisplayPort) : 60 Hz
Discrete graphics card : No
On-board graphics card dynamic frequency (max) : 1300 MHz
On-board graphics card model : Intel UHD Graphics P750
On-board graphics card refresh rate at maximum resolution (eDP – Integrated Flat Panel) : 60 Hz
Maximum on-board graphics card memory : 64 GB
On-board graphics card base frequency : 350 MHz
On-board graphics card refresh rate at maximum resolution (HDMI) : 60 Hz
On-board graphics card OpenGL version : 4.5
On-board graphics card 4K support : Yes
Commodity Classification Automated Tracking System (CCATS) : G167599
Export Control Classification Number (ECCN) : 5A992CN3
PCI Express slots version : 4.0
Execute Disable Bit : Yes
Supported instruction sets : AVX-512, AVX 2.0, SSE4.1, SSE4.2
Market segment : Server
Thermal Monitoring Technologies : Yes
PCI Express configurations : 1×8+3×4, 1×16+1×4, 2×8+1×4
Idle States : Yes
CPU configuration (max) : 1
Maximum number of PCI Express lanes : 20
Scalability : 1S
ECC : Yes
Maximum internal memory supported by processor : 128 GB
Memory types supported by processor : DDR4-SDRAM
Memory channels : Dual-channel
Tjunction : 100 °C
Processor package size : 37.5 x 37.5 mm
Maximum Enclave Size Support for Intel® SGX : 0.5 GB
Intel® Transactional Synchronization Extensions : No
Intel® Turbo Boost Technology 2.0 frequency : 5.1 GHz
Intel Trusted Execution Technology : Yes
Intel® Quick Sync Video Technology : Yes
Enhanced Intel SpeedStep Technology : Yes
Intel Software Guard Extensions (Intel SGX) : Yes
Intel® Memory Protection Extensions (Intel® MPX) : Yes
Intel® Boot Guard : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel® Secure Key : Yes
Intel® vPro™ Platform Eligibility : Yes
Intel® Clear Video HD Technology (Intel® CVT HD) : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel® Optane™ DC Persistent Memory Supported : No
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Intel 64 : Yes
Intel® InTru™ 3D Technology : Yes
Intel® OS Guard : Yes
Intel Clear Video Technology : Yes
Intel® Turbo Boost Technology : 2.0
Maximum internal memory : 128 GB
Harmonized System (HS) code : 85423119
Warnings : The product should be used in accordance with the manufacturer’s instructions to avoid damage., Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity.
