Intel Xeon Gold 5317 processor 3 GHz 18 MB

Description

Supported memory types : DDR4-SDRAM
Target market : Cloud Computing
Launch date : Q2’21
Number of UPI links : 3
Memory speed (max) : 2933 MHz
Status : Launched
Servicing status : Baseline Servicing
Processor cache : 18 MB
Processor threads : 24
Processor manufacturer : Intel
Processor boost frequency : 3.6 GHz
Component for : Server/workstation
Processor family : Intel® Xeon® Gold
Processor model : 5317
Processor series : Intel Xeon Gold 5000 Series
System bus rate : 11.2 GT/s
Processor ARK ID : 215272
Processor operating modes : 64-bit
Processor socket : LGA 4189
Thermal Design Power (TDP) : 150 W
Processor codename : Ice Lake
Processor cores : 12
Processor lithography : 10 nm
Cooler included : No
Box : No
Low priority cores : 8
Processor base frequency : 3 GHz
High priority core frequency : 3.2 GHz
Processor generation : 3rd Generation Intel® Xeon® Scalable
High priority cores : 4
Low priority core frequency : 2.8 GHz
On-board graphics card model : Not available
Discrete graphics card model : Not available
Discrete graphics card : No
On-board graphics card : No
Supported instruction sets : AVX-512, AVX 2.0, AVX, SSE4.2
Execute Disable Bit : Yes
PCI Express slots version : 4.0
Maximum number of PCI Express lanes : 64
Embedded options available : Yes
Scalability : 2S
Market segment : Server
Commodity Classification Automated Tracking System (CCATS) : G178966
Export Control Classification Number (ECCN) : 5A992CN3
ECC : Yes
Memory channels : Octa-channel
Maximum internal memory supported by processor : 6 TB
Memory types supported by processor : DDR4-SDRAM
Tcase : 84 °C
Processor package size : 77.5 x 56.5 mm
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel 64 : Yes
Intel Trusted Execution Technology : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel® Turbo Boost Technology : 2.0
Intel® Run Sure Technology : Yes
Intel® Volume Management Device (VMD) : Yes
AVX-512 Fused Multiply-Add (FMA) units : 2
Intel® Optane™ DC Persistent Memory Supported : Yes
Intel Software Guard Extensions (Intel SGX) : Yes
Mode-based Execute Control (MBE) : Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
Intel® Speed Shift Technology : Yes
Intel® Resource Director Technology (Intel® RDT) : Yes
Intel® Crypto Acceleration : Yes
Intel® Total Memory Encryption : Yes
Intel® Platform Firmware Resilience Support : Yes
Maximum Enclave Size Support for Intel® SGX : 64 GB
Intel® Transactional Synchronization Extensions : Yes
Maximum internal memory : 6 TB
Harmonized System (HS) code : 85423119
Warnings : The product should be used in accordance with the manufacturer’s instructions to avoid damage., Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity.
