Intel Xeon Gold 5317 Processor 3GHz

Description

Servicing status : Baseline Servicing
Number of UPI links : 3
Status : Launched
Supported memory types : DDR4-SDRAM
Target market : Cloud Computing
Launch date : Q2’21
Memory speed (max) : 2933 MHz
Processor lithography : 10 nm
Processor series : Intel Xeon Gold 5000 Series
Processor boost frequency : 3.6 GHz
Processor socket : LGA 4189
High priority cores : 4
Processor ARK ID : 215272
Processor family : Intel® Xeon® Gold
Processor codename : Ice Lake
Processor cache : 18 MB
Processor generation : 3rd Generation Intel® Xeon® Scalable
High priority core frequency : 3.2 GHz
Processor threads : 24
Component for : Server/workstation
Thermal Design Power (TDP) : 150 W
Low priority core frequency : 2.8 GHz
Low priority cores : 8
System bus rate : 11.2 GT/s
Cooler included : No
Processor manufacturer : Intel
Processor base frequency : 3 GHz
Processor model : 5317
Processor cores : 12
Processor operating modes : 64-bit
Discrete graphics card model : Not available
Discrete graphics card : No
On-board graphics card model : Not available
On-board graphics card : No
PCI Express slots version : 4.0
Embedded options available : Yes
Maximum number of PCI Express lanes : 64
Execute Disable Bit : Yes
Market segment : Server
Supported instruction sets : AVX-512, AVX, AVX 2.0, SSE4.2
Scalability : 2S
Commodity Classification Automated Tracking System (CCATS) : G178966
Export Control Classification Number (ECCN) : 5A992CN3
ECC : Yes
Maximum internal memory supported by processor : 6 TB
Memory types supported by processor : DDR4-SDRAM
Memory channels : Octa-channel
Tcase : 84 °C
Processor package size : 77.5 x 56.5 mm
Intel® Optane™ DC Persistent Memory Supported : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel® Resource Director Technology (Intel® RDT) : Yes
Intel® Run Sure Technology : Yes
Intel® Speed Shift Technology : Yes
Intel Trusted Execution Technology : Yes
Intel Software Guard Extensions (Intel SGX) : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel® Platform Firmware Resilience Support : Yes
Intel® Transactional Synchronization Extensions : Yes
Maximum Enclave Size Support for Intel® SGX : 64 GB
Intel 64 : Yes
Intel® Turbo Boost Technology : 2.0
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
Intel® Crypto Acceleration : Yes
Intel® Total Memory Encryption : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel® Volume Management Device (VMD) : Yes
AVX-512 Fused Multiply-Add (FMA) units : 2
Mode-based Execute Control (MBE) : Yes
Maximum internal memory : 6 TB
Harmonized System (HS) code : 85423119
