Intel Xeon Gold 5320 processor 2.2 GHz 39 MB Box, Tray

Description

Number of UPI links : 3
Servicing status : Baseline Servicing
Target market : Cloud Computing
Memory speed (max) : 2933 MHz
Status : Launched
Launch date : Q2’21
Supported memory types : DDR4-SDRAM
Processor lithography : 10 nm
System bus rate : 11.2 GT/s
Processor codename : Ice Lake
Processor operating modes : 64-bit
Processor threads : 52
Processor family : Intel® Xeon® Gold
Processor boost frequency : 3.4 GHz
Component for : Server/workstation
Processor cores : 26
Processor model : 5320
Processor manufacturer : Intel
Thermal Design Power (TDP) : 185 W
Processor base frequency : 2.2 GHz
High priority cores : 12
Processor generation : 3rd Generation Intel® Xeon® Scalable
Low priority core frequency : 2 GHz
Processor socket : LGA 4189
Low priority cores : 14
High priority core frequency : 2.5 GHz
Processor ARK ID : 215285
Processor cache : 39 MB
Cooler included : No
On-board graphics card model : Not available
Discrete graphics card model : Not available
Discrete graphics card : No
On-board graphics card : No
Maximum number of PCI Express lanes : 64
PCI Express slots version : 4.0
Embedded options available : No
Supported instruction sets : AVX, SSE4.2, AVX-512, AVX 2.0
Commodity Classification Automated Tracking System (CCATS) : G178966
Scalability : 2S
Execute Disable Bit : Yes
Market segment : Server
Export Control Classification Number (ECCN) : 5A992CN3
ECC : Yes
Memory types supported by processor : DDR4-SDRAM
Memory channels : Octa-channel
Memory clock speeds supported by processor : 2933
Maximum internal memory supported by processor : 6.14 TB
Tcase : 79 °C
Processor package size : 77.5 x 56.5 mm
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Intel® Turbo Boost Technology : 2.0
Intel® Run Sure Technology : Yes
AVX-512 Fused Multiply-Add (FMA) units : 2
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
Intel® Volume Management Device (VMD) : Yes
Intel® Transactional Synchronization Extensions : Yes
Mode-based Execute Control (MBE) : Yes
Intel 64 : Yes
Intel Software Guard Extensions (Intel SGX) : Yes
Intel® Resource Director Technology (Intel® RDT) : Yes
Maximum Enclave Size Support for Intel® SGX : 64 GB
Intel® Speed Shift Technology : Yes
Intel® Platform Firmware Resilience Support : Yes
Intel® Total Memory Encryption : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel Trusted Execution Technology : Yes
Intel® Crypto Acceleration : Yes
Intel® Optane™ DC Persistent Memory Supported : Yes
Intel Virtualization Technology (VT-x) : Yes
Maximum internal memory : 6 TB
Harmonized System (HS) code : 85423119
Warnings : Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity., The product should be used in accordance with the manufacturer’s instructions to avoid damage.
