Intel Xeon Gold 6326 processor 2.9 GHz 24 MB

Description

Supported memory types : DDR4-SDRAM
Memory speed (max) : 3200 MHz
Target market : Cloud Computing
Launch date : Q2’21
Number of UPI links : 3
Status : Launched
Servicing status : Baseline Servicing
Processor series : Intel Xeon Gold 6000 Series
Component for : Server/workstation
Processor ARK ID : 215274
Processor family : Intel® Xeon® Gold
Processor codename : Ice Lake
Processor boost frequency : 3.5 GHz
Processor operating modes : 64-bit
Processor lithography : 10 nm
Processor manufacturer : Intel
Processor model : 6326
Processor threads : 32
Box : No
Processor cores : 16
High priority cores : 4
System bus rate : 11.2 GT/s
High priority core frequency : 3 GHz
Processor socket : LGA 4189
Cooler included : No
Low priority cores : 12
Processor cache : 24 MB
Processor generation : 3rd Generation Intel® Xeon® Scalable
Thermal Design Power (TDP) : 185 W
Low priority core frequency : 2.6 GHz
Processor base frequency : 2.9 GHz
Discrete graphics card : No
On-board graphics card : No
Discrete graphics card model : Not available
On-board graphics card model : Not available
PCI Express slots version : 4.0
Market segment : Server
Supported instruction sets : AVX-512, AVX 2.0, SSE4.2, AVX
Execute Disable Bit : Yes
Maximum number of PCI Express lanes : 64
Scalability : 2S
Embedded options available : Yes
Commodity Classification Automated Tracking System (CCATS) : G178966
Export Control Classification Number (ECCN) : 5A992CN3
ECC : Yes
Memory channels : Octa-channel
Memory types supported by processor : DDR4-SDRAM
Tcase : 78 °C
Processor package size : 77.5 x 56.5 mm
Intel Trusted Execution Technology : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
Intel® Speed Shift Technology : Yes
Intel® Resource Director Technology (Intel® RDT) : Yes
Intel 64 : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Intel® Volume Management Device (VMD) : Yes
AVX-512 Fused Multiply-Add (FMA) units : 2
Intel® Run Sure Technology : Yes
Mode-based Execute Control (MBE) : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Maximum Enclave Size Support for Intel® SGX : 64 GB
Intel® Platform Firmware Resilience Support : Yes
Intel® Optane™ DC Persistent Memory Supported : Yes
Intel Software Guard Extensions (Intel SGX) : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel® Crypto Acceleration : Yes
Intel® Turbo Boost Technology : 2.0
Intel® Transactional Synchronization Extensions : Yes
Intel® Total Memory Encryption : Yes
Maximum internal memory : 6 TB
Harmonized System (HS) code : 85423119
Warnings : Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity., The product should be used in accordance with the manufacturer’s instructions to avoid damage.
