Intel Xeon Gold 6354 processor 3 GHz 39 MB

Description

Number of UPI links : 3
Launch date : Q2’21
Target market : Cloud Computing
Status : Launched
Supported memory types : DDR4-SDRAM
Memory speed (max) : 3200 MHz
Servicing status : Baseline Servicing
Processor model : 6354
System bus rate : 11.2 GT/s
Processor lithography : 10 nm
Processor boost frequency : 3.6 GHz
Processor family : Intel® Xeon® Gold
Processor cache : 39 MB
Component for : Server/workstation
Processor cores : 18
Processor threads : 36
Processor codename : Ice Lake
Processor operating modes : 64-bit
Processor socket : LGA 4189
Thermal Design Power (TDP) : 205 W
Box : No
Processor manufacturer : Intel
Processor ARK ID : 212460
Cooler included : No
Low priority cores : 10
Low priority core frequency : 2.8 GHz
High priority core frequency : 3.1 GHz
High priority cores : 8
Processor generation : 3rd Generation Intel® Xeon® Scalable
Processor base frequency : 3 GHz
On-board graphics card model : Not available
Discrete graphics card model : Not available
On-board graphics card : No
Discrete graphics card : No
Maximum number of PCI Express lanes : 64
PCI Express slots version : 4.0
Execute Disable Bit : Yes
Market segment : Server
Supported instruction sets : AVX, SSE4.2, AVX 2.0, AVX-512
Scalability : 2S
Commodity Classification Automated Tracking System (CCATS) : G178966
Export Control Classification Number (ECCN) : 5A992CN3
Memory channels : Octa-channel
ECC : Yes
Maximum internal memory supported by processor : 6 TB
Memory types supported by processor : DDR4-SDRAM
Tcase : 77 °C
Processor package size : 77.5 x 56.5 mm
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Trusted Execution Technology : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel® Turbo Boost Technology : 2.0
Mode-based Execute Control (MBE) : Yes
Intel 64 : Yes
AVX-512 Fused Multiply-Add (FMA) units : 2
Intel® Volume Management Device (VMD) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel Software Guard Extensions (Intel SGX) : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
Intel® Speed Shift Technology : Yes
Intel® Run Sure Technology : Yes
Intel® Optane™ DC Persistent Memory Supported : Yes
Intel® Resource Director Technology (Intel® RDT) : Yes
Maximum Enclave Size Support for Intel® SGX : 64 GB
Intel® Crypto Acceleration : Yes
Intel® Platform Firmware Resilience Support : Yes
Intel® Total Memory Encryption : Yes
Intel® Transactional Synchronization Extensions : Yes
Maximum internal memory : 6 TB
Harmonized System (HS) code : 85423119
Warnings : Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity., The product should be used in accordance with the manufacturer’s instructions to avoid damage.
