Intel Xeon Silver 4309Y processor 2.8 GHz 12 MB Box, Tray

Description

Launch date : Q2’21
Memory speed (max) : 2667 MHz
Target market : Cloud Computing
Status : Launched
Supported memory types : DDR4-SDRAM
Number of UPI links : 2
Servicing status : Baseline Servicing
Processor ARK ID : 215275
Processor threads : 16
Component for : Server/workstation
Processor manufacturer : Intel
Processor operating modes : 64-bit
Processor socket : LGA 4189
Processor cache : 12 MB
System bus rate : 10.4 GT/s
Processor codename : Ice Lake
Processor family : Intel Xeon Silver
Processor boost frequency : 3.6 GHz
Processor lithography : 10 nm
Processor cores : 8
Thermal Design Power (TDP) : 105 W
Processor model : 4309Y
Processor base frequency : 2.8 GHz
Cooler included : No
Performance-core base frequency : 2.8 GHz
Processor generation : 3rd Generation Intel® Xeon® Scalable
Discrete graphics card model : Not available
On-board graphics card : No
Discrete graphics card : No
On-board graphics card model : Not available
PCI Express slots version : 4.0
Maximum number of PCI Express lanes : 64
Embedded options available : No
Supported instruction sets : AVX-512, AVX, SSE4.2, AVX 2.0
Export Control Classification Number (ECCN) : 5A992CN3
Scalability : 2S
Execute Disable Bit : Yes
Commodity Classification Automated Tracking System (CCATS) : G178966
Market segment : Server
ECC : Yes
Memory clock speeds supported by processor : 2667 MHz
Memory channels : Octa-channel
Memory types supported by processor : DDR4-SDRAM
Maximum internal memory supported by processor : 6.14 TB
Tcase : 76 °C
Processor package size : 77.5 x 56.5 mm
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel Trusted Execution Technology : Yes
Intel® Turbo Boost Technology : 2.0
Intel 64 : Yes
Mode-based Execute Control (MBE) : Yes
Intel® Resource Director Technology (Intel® RDT) : Yes
Intel® Speed Shift Technology : Yes
AVX-512 Fused Multiply-Add (FMA) units : 2
Intel® Transactional Synchronization Extensions : Yes
Intel® Volume Management Device (VMD) : Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
Intel® Crypto Acceleration : Yes
Maximum Enclave Size Support for Intel® SGX : 8 GB
Intel® Total Memory Encryption : Yes
Intel® Optane™ DC Persistent Memory Supported : No
Intel Software Guard Extensions (Intel SGX) : Yes
Intel® Platform Firmware Resilience Support : Yes
Intel® Speed Select technology – Performance Profile (Intel® SST-PP) : Yes
Maximum internal memory : 6 TB
Harmonized System (HS) code : 85423119
Warnings : Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity., The product should be used in accordance with the manufacturer’s instructions to avoid damage.
