Intel Xeon Silver 4309Y processor 2.8 GHz 12 MB Box, Tray

Description

Number of UPI links : 2
Memory speed (max) : 2667 MHz
Target market : Cloud Computing
Servicing status : Baseline Servicing
Status : Launched
Launch date : Q2’21
Supported memory types : DDR4-SDRAM
Processor base frequency : 2.8 GHz
Processor generation : 3rd Generation Intel® Xeon® Scalable
Performance-core base frequency : 2.8 GHz
Processor model : 4309Y
Processor codename : Ice Lake
Thermal Design Power (TDP) : 105 W
Cooler included : No
Processor cache : 12 MB
Processor socket : LGA 4189
Processor threads : 16
Processor manufacturer : Intel
Processor boost frequency : 3.6 GHz
Processor family : Intel Xeon Silver
Component for : Server/workstation
Processor operating modes : 64-bit
Package type : Box, Tray
System bus rate : 10.4 GT/s
Processor lithography : 10 nm
Processor ARK ID : 215275
Processor cores : 8
Discrete graphics card model : Not available
On-board graphics card : No
Discrete graphics card : No
On-board graphics card model : Not available
Commodity Classification Automated Tracking System (CCATS) : G178966
Export Control Classification Number (ECCN) : 5A992CN3
PCI Express slots version : 4.0
Supported instruction sets : AVX-512, AVX, SSE4.2, AVX 2.0
Execute Disable Bit : Yes
Scalability : 2S
Market segment : Server
Embedded options available : No
Maximum number of PCI Express lanes : 64
Maximum internal memory supported by processor : 6.14 TB
Memory channels : Octa-channel
Memory clock speeds supported by processor : 2667 MHz
ECC : Yes
Memory types supported by processor : DDR4-SDRAM
Tcase : 76 °C
Processor package size : 77.5 x 56.5 mm
Intel® Resource Director Technology (Intel® RDT) : Yes
Mode-based Execute Control (MBE) : Yes
Intel® Volume Management Device (VMD) : Yes
Intel® Speed Select technology – Performance Profile (Intel® SST-PP) : Yes
Intel® Optane™ DC Persistent Memory Supported : No
Maximum Enclave Size Support for Intel® SGX : 8 GB
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
Intel® Crypto Acceleration : Yes
Intel® Platform Firmware Resilience Support : Yes
Intel® Total Memory Encryption : Yes
Intel® Transactional Synchronization Extensions : Yes
Intel Software Guard Extensions (Intel SGX) : Yes
AVX-512 Fused Multiply-Add (FMA) units : 2
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Intel 64 : Yes
Intel® Speed Shift Technology : Yes
Intel® Turbo Boost Technology : 2.0
Intel Trusted Execution Technology : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Maximum internal memory : 6 TB
Harmonized System (HS) code : 85423119
Warnings : Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity., The product should be used in accordance with the manufacturer’s instructions to avoid damage.
