Intel Xeon Silver 4314 processor 2.4 GHz 24 MB TRAY

Description

Servicing status : Baseline Servicing
Launch date : Q2’21
Number of UPI links : 2
Memory speed (max) : 2667 MHz
Supported memory types : DDR4-SDRAM
Target market : Cloud Computing
Status : Launched
Processor lithography : 10 nm
Processor boost frequency : 3.4 GHz
Processor codename : Ice Lake
Processor operating modes : 64-bit
Box : No
Processor manufacturer : Intel
Processor cores : 16
Processor model : 4314
Processor ARK ID : 215269
Processor family : Intel Xeon Silver
Processor base frequency : 2.4 GHz
Component for : Server/workstation
Processor socket : LGA 4189
Thermal Design Power (TDP) : 135 W
System bus rate : 10.4 GT/s
Processor threads : 32
Processor cache : 24 MB
Cooler included : No
Processor generation : 3rd Generation Intel® Xeon® Scalable
On-board graphics card model : Not available
Discrete graphics card model : Not available
On-board graphics card : No
Discrete graphics card : No
PCI Express slots version : 4.0
Embedded options available : Yes
Maximum number of PCI Express lanes : 64
Market segment : Server
Supported instruction sets : AVX-512, SSE4.2, AVX 2.0, AVX
Scalability : 2S
Export Control Classification Number (ECCN) : 5A992CN3
Execute Disable Bit : Yes
Commodity Classification Automated Tracking System (CCATS) : G178966
Memory clock speeds supported by processor : 2667 MHz
Maximum internal memory supported by processor : 6.14 TB
Memory types supported by processor : DDR4-SDRAM
ECC : Yes
Memory channels : Octa-channel
Tcase : 86 °C
Processor package size : 77.5 x 56.5 mm
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Intel® Turbo Boost Technology : 2.0
AVX-512 Fused Multiply-Add (FMA) units : 2
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel Software Guard Extensions (Intel SGX) : Yes
Mode-based Execute Control (MBE) : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel® Volume Management Device (VMD) : Yes
Intel 64 : Yes
Intel® Speed Shift Technology : Yes
Intel Trusted Execution Technology : Yes
Intel® Resource Director Technology (Intel® RDT) : Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
Intel® Optane™ DC Persistent Memory Supported : Yes
Maximum Enclave Size Support for Intel® SGX : 8 GB
Intel® Platform Firmware Resilience Support : Yes
Intel® Transactional Synchronization Extensions : Yes
Intel® Crypto Acceleration : Yes
Intel® Total Memory Encryption : Yes
Maximum internal memory : 6 TB
Harmonized System (HS) code : 85423119
