Intel Xeon Silver 4509Y processor 2.6 GHz 22.5 MB

Description

Number of UPI links : 2
Status : Launched
Launch date : Q4’23
Servicing status : Baseline Servicing
Package carrier : E1B
Processor manufacturer : Intel
Processor boost frequency : 4.1 GHz
Processor codename : Sapphire Rapids
Processor threads : 16
Processor socket : LGA 4677 (Socket E)
Processor family : Intel Xeon Silver
Stepping : U1
Processor operating modes : 64-bit
Processor cache : 22.5 MB
Processor ARK ID : 236636
Thermal Design Power (TDP) : 125 W
Processor cores : 8
Processor model : 4509Y
Box : No
Processor generation : Intel Xeon Scalable 5th Gen
Processor base frequency : 2.6 GHz
Intel® UPI Speed : 16 GT/s
On-board graphics card : No
Discrete graphics card model : Not available
Discrete graphics card : No
On-board graphics card model : Not available
Embedded options available : Yes
Maximum number of PCI Express lanes : 80
PCI Express slots version : 5.0
Supported instruction sets : AVX 2.0, SSE4.2, AVX-512, AMX, AVX
Scalability : 2S
Market segment : Server
Execute Disable Bit : Yes
Commodity Classification Automated Tracking System (CCATS) : 740.17B1
Export Control Classification Number (ECCN) : 5A992C
Use conditions : Server/Enterprise
ECC : Yes
Memory channels : Octa-channel
Memory clock speeds supported by processor : 4400 MHz
Maximum internal memory supported by processor : 4 TB
Memory types supported by processor : DDR5-SDRAM
Tcase : 84 °C
DTS Max : 100 °C
Processor package size : 77.5 x 56.5 mm
Intel 64 : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Intel® OS Guard : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel Trusted Execution Technology : Yes
Intel® Turbo Boost Technology : 2.0
AVX-512 Fused Multiply-Add (FMA) units : 2
Intel Software Guard Extensions (Intel SGX) : Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
Mode-based Execute Control (MBE) : Yes
Intel® Speed Shift Technology : Yes
Intel® Boot Guard : Yes
Intel® Resource Director Technology (Intel® RDT) : Yes
Intel® Volume Management Device (VMD) : Yes
Intel® Advanced Matrix Extensions (AMX) : Yes
Intel® Platform Firmware Resilience Support : Yes
Intel® Total Memory Encryption : Yes
Maximum Enclave Size Support for Intel® SGX : 64 GB
Intel® Crypto Acceleration : Yes
Intel® Transactional Synchronization Extensions : Yes
Intel® Control-flow Enforcement Technology (CET) : Yes
Intel® Total Memory Encryption – Multi Key : Yes
Intel® QuickAssist Software Acceleration : Yes
Intel® Data Streaming Accelerator (DSA) : 1 default devices
Intel® On Demand Feature Activation : Yes
Maximum internal memory : 4 TB
Harmonized System (HS) code : 8542310001
Warnings : Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity., The product should be used in accordance with the manufacturer’s instructions to avoid damage.
