Description
Processor socket : LGA 1700
Supported processor sockets : LGA 1700
Maximum number of SMP processors : 1
Processor manufacturer : Intel
Compatible processor series : Intel Pentium Gold G7400T, Intel Xeon E-2400, Intel Pentium Gold G7400
Parallel processing technology support : Not supported
Motherboard chipset : Intel C262
Product colour : Blue
Motherboard chipset family : Intel
Motherboard form factor : micro ATX
Component for : Server/workstation
Supported memory clock speeds : 4400 MHz, 4000, 3600
Memory channels : Dual-channel
Number of memory slots : 4
Supported memory types : DDR5 UDIMM
Memory slots type : DIMM
Depth : 244 mm
Width : 244 mm
Wi-Fi : No
Ethernet LAN : Yes
Ethernet interface type : 1 Gigabit Ethernet
Number of SATA connectors : 8
CPU fan connector : Yes
Number of chassis fan connectors : 5
12V power connector : Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors : 1
ATX Power connector (24-pin) : Yes
Package width : 321 mm
Package depth : 308,5 mm
Package height : 78,5 mm
DFU / User manual : Y
Cables included : 2 x SATA
RAID support : Yes
Supported storage drive types : HDD & SSD
Supported storage drive interfaces : M.2, SATA III
Supported RAID configuration : 0,1,5,10
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 2
VGA (D-Sub) ports quantity : 1
COM ports quantity : 1
Ethernet LAN (RJ-45) ports : 2
Port Management LAN : Yes, 1
PCI Express x8 (Gen 4.x) slots : 1
PCI Express x16 (Gen 5.x) slots : 1
Warnings : Do not disassemble to avoid damage to internal components and loss of warranty., The motherboard may contain electronic components hazardous to health – avoid direct contact., Do not open or disassemble the motherboard.
