Description
Processor family : Annapurna Labs
Processor manufacturer : Annapurna Labs
Processor model : AL324
Processor frequency : 1.7 GHz
Processor cores : 4
Memory slots : 1
Maximum RAM supported : 16 GB
Internal memory : 4 GB
Memory form factor : UDIMM
Internal memory type : DDR4
Flash memory : 512 MB
Product colour : Black
LED indicators : HDD, LAN, Status
Cooling type : Active
Number of fans : 2 fan(s)
Fan diameter : 7 cm
Chassis type : Rack (2U)
Fan diameter 2 : 7 cm
AC input frequency : 50 – 60 Hz
AC input voltage : 100 – 240 V
Power consumption (typical) : 83.57 W
Power supply location : Built-in
Fan voltage : 12 V
Number of power supply units : 2
Power supply unit (PSU) capacity : 250 W
Storage temperature (T-T) : -20 – 70 °C
Operating temperature (T-T) : 0 – 40 °C
Operating relative humidity (H-H) : 5 – 95%
Weight : 11.3 kg
Package weight : 17.3 kg
Depth : 534 mm
Width : 482 mm
Height : 89 mm
Wake-on-LAN ready : Yes
DHCP client : Yes
Ethernet LAN data rates : 10000 Mbit/s, 1000 Mbit/s, 2500, 100
WLAN adapter supported : Yes
Link aggregation : Yes
Dynamic DNS (DDNS) : Yes
Supported network protocols : PPTP, L2TP/IPSec, OpenVPN, QBelt
DHCP server : Yes
iSCSI support : Yes
Jumbo frames support : Yes
Load balancing system : Yes
Ethernet LAN : Yes
Reset button : Yes
Web-based management : Yes
Security algorithms : HTTPS, FIPS 140-2, SSH, 256-bit AES, SSL/TLS
Device class : Small & Medium Business
Universal Plug and Play (UPnP) : Yes
Hot spare : Yes
Disk scan : Yes
Backup function : Yes
USB copy function : Yes
Type : NAS
Snapshot : Yes
S.M.A.R.T. support : Yes
System log : Yes
On/off switch : Yes
Backup features : iSCSI LUN, Cloud
Built-in FTP server : Yes
Browser supported : Mozilla Firefox, Microsoft Internet Explorer 10+, Apple Safari 7+, Google Chrome
Buzzer : Yes
Share folder : CIFS/SMB
Noise level : 32.2 dB
Access Control List (ACL) : Yes
Multilingual support : Yes
Management protocols : SNMP
Number of screws : 84
Cables included : LAN (RJ-45), AC
Operating system installed : QNAP QTS
Mac operating systems supported : Mac OS X 10.10 Yosemite, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.11 El Capitan, Mac OS X 10.15 Catalina
Server operating systems supported : Windows Server 2012, Windows Server 2019, Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016
Operating system version : 5.0.0
Windows operating systems supported : Windows 7, Windows 8, Windows 10
Linux operating systems supported : Yes
Supported storage drive interfaces : Serial ATA II, Serial ATA III
Supported storage drive types : HDD & SSD
RAID support : Yes
RAID levels : JBOD, 6, 1, 10, 0, 5
Installed storage drive type : No
Hot-swap drive bays : Yes
Online RAID expansion : Yes
Online RAID migration : Yes
Storage drives installed : No
Supported file systems : ext4, ext3, NTFS, HFS+, FAT32
RAID rebuild : Yes
Total installed storage capacity : 0 TB
Storage drive capacity : 0 GB
Disk roaming : Yes
Bad block scan : Yes
Number of storage drives supported : 12
Storage drive sizes supported : 3.5", 2.5
Ethernet LAN (RJ-45) ports : 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 4
USB port : Yes
Fiber ports quantity : 2
Fiber optic connector : SFP+
Harmonized System (HS) code : 84714100
Warnings : Do not dispose of the device in the regular rubbish bin. The product requires special disposal., Avoid contact with liquids., Do not dismantle the appliance yourself.
