Description
Processor cores : 8
Processor manufacturer : Intel
Processor family : Intel Atom®
Processor threads : 8
Processor model : C5125
Processor frequency : 2.8 GHz
Memory slots : 4
Maximum RAM supported : 128 GB
Internal memory : 8 GB
Internal memory type : DDR4
Memory form factor : UDIMM
ECC : Yes
Flash memory : 5000 MB
Built-in display : Yes
Cooling type : Active
Drive bay locking : Yes
Fan diameter : 9.2 cm
Number of fans : 5 fan(s)
LED indicators : Status, HDD, USB, M.2, LAN, Power, SSD
Product colour : Black
Cable lock slot type : Kensington
Chassis type : Tower
Fan diameter 2 : 9.7 cm
Cable lock slot : Yes
Power supply location : Built-in
AC input voltage : 100 – 240 V
Fan voltage : 12 V
Number of power supply units : 1
Power supply unit (PSU) capacity : 550 W
Power consumption (HDD standby) : 94.957 W
Power consumption (typical) : 104.65 W
Operating temperature (T-T) : 0 – 40 °C
Storage temperature (T-T) : -20 – 70 °C
Operating relative humidity (H-H) : 5 – 95%
Storage relative humidity (H-H) : 5 – 95%
Width : 369.9 mm
Height : 303.8 mm
Depth : 319.8 mm
Ethernet LAN data rates : 10, 100, 1000 Mbit/s, 2500
DHCP server : Yes
DHCP client : Yes
iSCSI support : Yes
Dynamic DNS (DDNS) : Yes
Wake-on-LAN ready : Yes
Ethernet LAN : Yes
Jumbo frames support : Yes
Security algorithms : SSH, HTTPS, FIPS 140-2, TLS, 256-bit AES
Browser supported : Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox
Backup function : Yes
Device class : Small & Medium Business
Access Control List (ACL) : Yes
Backup features : Cloud, USB drive, iSCSI LUN
Share folder access right management : Yes
Share folder : CIFS/SMB, AFP, NFS, FTP
Type : NAS
Reset button : Yes
Hot spare : Yes
Multilingual support : Yes
Password authentication : Yes
S.M.A.R.T. support : Yes
Built-in FTP server : Yes
Number of users : 4096 user(s)
System log : Yes
USB copy function : Yes
On/off switch : Yes
Disk scan : Yes
Snapshot : Yes
Buzzer : Yes
Management protocols : SNMP V2/V3
Drive tray key included : Yes
Number of screws : 72
Cables included : LAN (RJ-45), AC
Power cables quantity : 1
Operating system installed : QNAP Turbo System
Windows operating systems supported : Windows 8, Windows 7, Windows 11, Windows 10
Server operating systems supported : Windows Server 2019, Windows Server 2012 R2, Windows Server 2016, Windows Server 2012, Windows Server 2008 R2
Mac operating systems supported : Yes
Linux operating systems supported : Yes
Operating system version : 5.0.1
RAID levels : JBOD, 5, 6, 50, 60, 10, 1, 0
Supported file systems : FAT32, exFAT, ext4, HFS+, ext3, NTFS
Disk roaming : Yes
Online RAID migration : Yes
Bad block scan : Yes
Storage drives installed : No
Online RAID expansion : Yes
Supported storage drive types : HDD & SSD
Supported storage drive interfaces : Serial ATA II, Serial ATA III
RAID support : Yes
Number of M.2 (M & B) slots : 2
Number of storage drives supported : 16
Installed storage drive type : No
RAID rebuild : Yes
Hot-swap drive bays : Yes
Storage drive sizes supported : 3.5", 2.5, M.2
Ethernet LAN (RJ-45) ports : 2
Concurrent connections : 700
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 4
USB port : Yes
PCI Express x4 (Gen 3.x) slots : 3
