Description
Processor family : Annapurna Labs
Processor cores : 4
Processor model : Alpine AL-324
Processor manufacturer : Annapurna Labs
Processor frequency : 1.7 GHz
Memory slots : 1
Internal memory type : DDR4
Flash memory : 512 MB
Internal memory : 2 GB
Memory form factor : UDIMM
Maximum RAM supported : 16 GB
LED indicators : LAN, HDD, Status
Chassis type : Rack (1U)
Cooling type : Active
Product colour : Black
Number of fans : 2 fan(s)
Fan diameter : 4 cm
Power supply location : Built-in
Fan voltage : 12 V
AC input voltage : 100 – 240 V
Power consumption (typical) : 53.343 W
Power supply unit (PSU) capacity : 250 W
Number of power supply units : 2
Operating relative humidity (H-H) : 5 – 95%
Storage temperature (T-T) : -20 – 70 °C
Operating temperature (T-T) : 0 – 40 °C
Weight : 8.12 kg
Width : 439 mm
Height : 44 mm
Depth : 499 mm
Ethernet LAN data rates : 2500, 10000 Mbit/s, 100, 1000 Mbit/s
DHCP client : Yes
Wake-on-LAN ready : Yes
iSCSI support : Yes
Load balancing system : Yes
Ethernet LAN : Yes
Ethernet LAN data rate supported (max) : 10000 Mbit/s
Link aggregation : Yes
DHCP server : Yes
Supported network protocols : PPTP, L2TP/IPSec, OpenVPN, QBelt
Jumbo frames support : Yes
WLAN adapter supported : Yes
On/off switch : Yes
Web-based management : Yes
Security algorithms : HTTPS, FIPS 140-2, SSL/TLS, 256-bit AES, SSH
Backup features : iSCSI LUN, Cloud
Multilingual support : Yes
S.M.A.R.T. support : Yes
Type : NAS
Browser supported : Mozilla Firefox, Microsoft Internet Explorer 10+, Apple Safari 7+, Google Chrome
Access Control List (ACL) : Yes
Buzzer : Yes
Reset button : Yes
Hot spare : Yes
Built-in FTP server : Yes
Universal Plug and Play (UPnP) : Yes
Backup function : Yes
Snapshot : Yes
USB copy function : Yes
Device class : Small & Medium Business
System log : Yes
Share folder : CIFS/SMB
Cables included : LAN (RJ-45), AC
Number of screws : 28
Mac operating systems supported : Mac OS X 10.10 Yosemite, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.11 El Capitan, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Server operating systems supported : Windows Server 2019, Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016, Windows Server 2012
Windows operating systems supported : Windows 7, Windows 8, Windows 10
Operating system version : 5.0.0
Linux operating systems supported : Yes
RAID levels : 10, 0, JBOD, 6, 1, 5
RAID support : Yes
Online RAID expansion : Yes
Installed storage drive type : No
Supported storage drive types : HDD & SSD
Supported file systems : HFS+, ext4, ext3, NTFS, FAT32
Storage drives installed : No
Supported storage drive interfaces : Serial ATA II, Serial ATA III
Online RAID migration : Yes
RAID rebuild : Yes
Bad block scan : Yes
Number of storage drives supported : 4
Hot-swap drive bays : Yes
Storage drive sizes supported : 3.5", 2.5
Ethernet LAN (RJ-45) ports : 2
USB port : Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 4
Fiber ports quantity : 2
Fiber optic connector : SFP+
Harmonized System (HS) code : 84714100
