Description
CPU configuration (max) : 1
On-board graphics card model : Intel® UHD Graphics
Number of processors supported : 1
Processor family : Intel® Celeron®
Processor cores : 4
Processor manufacturer : Intel
Processor threads : 4
Processor model : N5095
Processor boost frequency : 2.9 GHz
Internal memory type : DDR4
Memory form factor : SO-DIMM
Maximum RAM supported : 16 GB
Internal memory : 8 GB
Memory slots : 2
Flash memory : 4000 MB
LED indicators : Status, Power, HDD, USB, LAN, SSD
Cooling type : Active
Product colour : Black
Number of fans : 3 fan(s)
Chassis type : Rack (1U)
Fan diameter : 4 cm
Power consumption (typical) : 35.297 W
AC input voltage : 100 – 240 V
AC input frequency : 50 – 60 Hz
Fan voltage : 12 V
Power consumption (HDD standby) : 21.105 W
Power supply location : Built-in
Power supply unit (PSU) capacity : 100 W
Operating relative humidity (H-H) : 5 – 95%
Storage relative humidity (H-H) : 5 – 95%
Storage temperature (T-T) : -20 – 70 °C
Operating temperature (T-T) : 0 – 40 °C
Weight : 4.35 kg
Depth : 321.3 mm
Height : 43.3 mm
Package weight : 5.91 kg
Width : 482.6 mm
Ethernet LAN data rates : 100, 10, 2500, 1000 Mbit/s
Ethernet LAN : Yes
Wake-on-LAN ready : Yes
DHCP client : Yes
Jumbo frames support : Yes
iSCSI support : Yes
Dynamic DNS (DDNS) : Yes
DHCP server : Yes
Reset button : Yes
Security algorithms : SSH, 256-bit AES, HTTPS, FIPS 140-2
Type : NAS
On/off switch : Yes
Share folder : CIFS/SMB
Disk scan : Yes
Snapshot : Yes
Device class : Small & Medium Business
Built-in FTP server : Yes
Password authentication : Yes
S.M.A.R.T. support : Yes
Backup features : Cloud, iSCSI LUN
Backup function : Yes
Multilingual support : Yes
Buzzer : Yes
System log : Yes
Access Control List (ACL) : Yes
Browser supported : Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox
Hot spare : Yes
Quick installation guide : Yes
Cables included : LAN (RJ-45), AC
Number of screws : 28
Rack mount kit : Yes
Power cables quantity : 1
Enhanced Intel SpeedStep Technology : Yes
Intel Trusted Execution Technology : No
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Idle States : Yes
Intel 64 : Yes
Windows operating systems supported : Windows 10 Home x64, Windows 8, Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows 11, Windows 10 Enterprise, Windows 7 Home Basic x64, Windows 10 Home, Windows 7 Starter x64, Windows 10 Pro x64, Windows 8 Enterprise, Windows 8 x64, Windows 10 Education, Windows 7 Home Basic, Windows 7 Ultimate, Windows 10 Education x64, Windows 8 Pro x64, Windows 10 Pro, Windows 7 Home Premium, Windows 7 Starter, Windows 10 IoT Enterprise, Windows 10, Windows 10 IOT Core, Windows 8 Enterprise x64, Windows 8 Pro, Windows 7 Enterprise, Windows 7 Professional x64, Windows 7 Ultimate x64, Windows 7 x64, Windows 10 Enterprise x64, Windows 10 x64, Windows 11 x64, Windows 7 Professional, Windows 7
Mac operating systems supported : Mac OS X 10.2 Jaguar, Mac OS X 13.0 Ventura, Mac OS X 10.15.3 Catalina, Mac OS X 10.11 El Capitan, Mac OS X 12.0 Monterey, Mac OS X 10.10 Yosemite, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur
Operating system installed : QNAP Turbo System
Server operating systems supported : Windows Server 2008 R2, Windows Server 2019, Windows Server 2012 R2, Windows Server 2016, Windows Server 2012
Operating system version : 5.0.0
Linux operating systems supported : Yes
Supported storage drive interfaces : Serial ATA III, Serial ATA II
RAID levels : 10, JBOD, 0, 1, 6, 5
Supported storage drive types : HDD & SSD
RAID support : Yes
Number of storage drives supported : 4
Supported file systems : ext4, ext3, NTFS, exFAT, FAT32, HFS+
Storage drives installed : No
Storage drive sizes supported : M.2, 2.5, 3.5"
Online RAID migration : Yes
Hot-swap drive bays : Yes
Installed storage drive type : No
Number of M.2 (M & B) slots : 2
Disk roaming : Yes
Online RAID expansion : Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity : 2
Ethernet LAN (RJ-45) ports : 2
HDMI version : 1.4b
USB 2.0 ports quantity : 2
HDMI ports quantity : 1
USB port : Yes
