Description
Processor boost frequency : 2.9 GHz
Processor family : Intel® Celeron®
Processor threads : 4
On-board graphics card model : Intel® UHD Graphics
Processor cores : 4
CPU configuration (max) : 1
Processor manufacturer : Intel
Processor model : N5095
Memory form factor : SO-DIMM
Internal memory : 8 GB
Maximum RAM supported : 16 GB
Flash memory : 4000 MB
Memory slots : 2
Internal memory type : DDR4
Product colour : Black
Cooling type : Active
Chassis type : Rack (1U)
LED indicators : LAN, Status, Power, HDD
Number of fans : 2 fan(s)
Fan diameter : 4 cm
Number of power supply units : 1
AC input frequency : 50 – 60 Hz
Fan voltage : 12 V
AC input voltage : 100 – 240 V
Power supply location : Built-in
Power consumption (typical) : 36.81 W
Power supply unit (PSU) capacity : 250 W
Power consumption (sleep) : 22.285 W
Operating temperature (T-T) : 0 – 40 °C
Operating relative humidity (H-H) : 5 – 95%
Storage temperature (T-T) : -20 – 70 °C
Depth : 479 mm
Weight : 6.6 kg
Width : 430 mm
Height : 43.3 mm
Package weight : 8.54 kg
Ethernet LAN data rates : 10, 2500 Mbit/s, 100, 1000 Mbit/s
Ethernet LAN : Yes
Wake-on-LAN ready : Yes
DHCP client : Yes
iSCSI support : Yes
Jumbo frames support : Yes
DHCP server : Yes
Dynamic DNS (DDNS) : Yes
Reset button : Yes
S.M.A.R.T. support : Yes
Security algorithms : 256-bit AES, HTTPS, FIPS 140-2, SSH
Browser supported : Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox
Type : NAS
On/off switch : Yes
System log : Yes
Hot spare : Yes
Built-in FTP server : Yes
Disk scan : Yes
Multilingual support : Yes
Buzzer : Yes
Share folder : CIFS/SMB
Backup features : Cloud, iSCSI LUN
Access Control List (ACL) : Yes
Device class : Small & Medium Business
Backup function : Yes
Snapshot : Yes
Quick start guide : Yes
Power cables quantity : 1
Number of screws : 84
Cables included : AC, LAN (RJ-45)
Idle States : Yes
Intel Trusted Execution Technology : No
Enhanced Intel SpeedStep Technology : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel 64 : Yes
Linux operating systems supported : Ubuntu 14.10, Ubuntu 15.04, Ubuntu 15.10, CentOS 7.0, Ubuntu 18.04 LTS, Ubuntu 22.04, Red Hat Enterprise Linux WS 7.0, Ubuntu 17.10, Ubuntu 20.04 LTS, Ubuntu 16.04, Ubuntu 14.04, Ubuntu 16.10
Mac operating systems supported : Mac OS X 10.13 High Sierra, Mac OS X 10.11 El Capitan, Mac OS X 12.0 Monterey, Mac OS X 10.10 Yosemite, Mac OS X 10.12 Sierra, Mac OS X 10.15.3 Catalina, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 10.14 Mojave, Mac OS X 13.0 Ventura
Server operating systems supported : Windows Server 2012 R2, Windows Server 2016, Windows Server 2008 R2, Windows Server 2019, Windows Server 2012
Other operating systems supported : Solaris 11, IBM AIX 7.2, IBM AIX 7.1, Solaris 10
Operating system version : 5.0.1
Operating system installed : QNAP Turbo System
Windows operating systems supported : Windows 7, Windows 8, Windows 10, Windows 11
RAID support : Yes
RAID levels : 5, 10, 1, JBOD, 6, 0
Supported file systems : exFAT, ext3, NTFS, ext4, FAT32, HFS+
Online RAID expansion : Yes
Online RAID migration : Yes
Disk roaming : Yes
Number of storage drives supported : 4
RAID rebuild : Yes
Supported storage drive types : HDD & SSD
Supported storage drive interfaces : Serial ATA II, Serial ATA III
Installed storage drive type : No
Storage drive sizes supported : 2.5, 3.5"
Storage drives installed : No
Hot-swap drive bays : Yes
HDMI ports quantity : 1
Concurrent connections : 1500
Ethernet LAN (RJ-45) ports : 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity : 2
HDMI version : 1.4b
USB port : Yes
USB 2.0 ports quantity : 2
PCI Express x2 (Gen 3.x) slots : 1
Harmonized System (HS) code : 84714100
