Description
On-board graphics card model : Intel® UHD Graphics
Processor family : Intel® Celeron®
Processor threads : 4
CPU configuration (max) : 1
Processor cores : 4
Processor manufacturer : Intel
Processor model : N5095
Processor boost frequency : 2.9 GHz
Maximum RAM supported : 8 GB
Internal memory : 8 GB
Flash memory : 4000 MB
Cooling type : Active
Fan diameter : 4 cm
LED indicators : LAN, Status, Power, HDD
Product colour : Black
Number of fans : 2 fan(s)
Chassis type : Rack (1U)
Power consumption (typical) : 51.404 W
Power consumption (HDD standby) : 37.469 W
AC input voltage : 100 – 240 V
Power supply location : Built-in
Fan voltage : 12 V
Redundant power supply (RPS) support : Yes
Number of power supply units : 2
Power supply unit (PSU) capacity : 250 W
Operating temperature (T-T) : 0 – 40 °C
Operating relative humidity (H-H) : 5 – 95%
Storage temperature (T-T) : -20 – 70 °C
Storage relative humidity (H-H) : 5 – 95%
Height : 43.3 mm
Depth : 479 mm
Weight : 8.12 kg
Width : 430 mm
Package weight : 10.1 kg
Ethernet LAN data rates : 100, 10, 1000 Mbit/s, 2500
DHCP client : Yes
Ethernet LAN : Yes
iSCSI support : Yes
Wake-on-LAN ready : Yes
Jumbo frames support : Yes
Dynamic DNS (DDNS) : Yes
DHCP server : Yes
Access Control List (ACL) : Yes
Browser supported : Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox
On/off switch : Yes
Multilingual support : Yes
S.M.A.R.T. support : Yes
Built-in FTP server : Yes
Security algorithms : 256-bit AES, SSH, HTTPS, FIPS 140-2
Buzzer : Yes
Reset button : Yes
Hot spare : Yes
Type : NAS
Snapshot : Yes
Share folder : CIFS/SMB
System log : Yes
Device class : Small & Medium Business
Backup features : Cloud, iSCSI LUN
Backup function : Yes
Disk scan : Yes
Cables included : LAN (RJ-45), AC
Number of screws : 84
Power cables quantity : 2
Enhanced Intel SpeedStep Technology : Yes
Intel Trusted Execution Technology : No
Intel 64 : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Idle States : Yes
Server operating systems supported : Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2012
Mac operating systems supported : Yes
Linux operating systems supported : Yes
Operating system installed : QNAP Turbo System
Other operating systems supported : Solaris 10
Windows operating systems supported : Windows 11, Windows 10, Windows 8, Windows 7
Operating system version : 5.0.1
RAID rebuild : Yes
Installed storage drive type : No
RAID levels : 10, 6, 1, 0, JBOD, 5
Supported file systems : ext4, HFS+, ext3, NTFS, FAT32, exFAT
RAID support : Yes
Online RAID expansion : Yes
Number of storage drives supported : 4
Supported storage drive types : HDD & SSD
Supported storage drive interfaces : Serial ATA II, Serial ATA III
Disk roaming : Yes
Online RAID migration : Yes
Storage drive sizes supported : 2.5, 3.5"
Storage drives installed : No
Hot-swap drive bays : Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity : 2
USB port : Yes
HDMI ports quantity : 1
PCI Express x2 (Gen 3.x) slots : 1
Ethernet LAN (RJ-45) ports : 2
Concurrent connections : 1500
USB 2.0 ports quantity : 2
HDMI version : 1.4b
Harmonized System (HS) code : 84714100
