Description
Processor frequency : 2.2 GHz
Processor manufacturer : AMD
Processor cores : 4
Processor model : V1500B
On-board graphics card model : Not available
Processor family : Ryzen Embedded
Processor generation : AMD Ryzen Embedded V1000 Series
Processor threads : 8
ECC : Yes
Internal memory type : DDR4
Memory slots : 2
Maximum RAM supported : 64 GB
Flash memory : 5000 MB
Memory form factor : SO-DIMM
Internal memory : 8 GB
LED indicators : LAN, Status, USB, SSD, Power
Product colour : Black
Chassis type : Tower
Fan diameter 2 : 6 cm
Number of fans : 2 fan(s)
Drive bay locking : Yes
Fan diameter : 12 cm
Cooling type : Active
AC input voltage : 100 – 240 V
Power consumption (typical) : 29.792 W
Power consumption (HDD standby) : 19.576 W
Number of power supply units : 1
Power supply location : Built-in
Output current : 3.5 A
Power supply unit (PSU) capacity : 250 W
AC input frequency : 50-60 Hz
Storage temperature (T-T) : -20 – 70 °C
Operating relative humidity (H-H) : 5 – 95%
Operating temperature (T-T) : 0 – 40 °C
Storage relative humidity (H-H) : 5 – 95%
Height : 188.2 mm
Width : 199.3 mm
Weight : 5.03 kg
Depth : 280.8 mm
Ethernet LAN data rates : 100, 1000 Mbit/s, 2500
Wake-on-LAN ready : Yes
Ethernet LAN : Yes
Jumbo frames support : Yes
Dynamic DNS (DDNS) : Yes
DHCP server : Yes
On/off switch : Yes
Security algorithms : 256-bit AES, SSH, SSL/TLS, FIPS 140-2
Reset button : Yes
Backup function : Yes
S.M.A.R.T. support : Yes
Backup features : Cloud, USB drive, iSCSI LUN
Device class : Small & Medium Business
Browser supported : Mozilla Firefox, Microsoft Edge, Google Chrome, Apple Safari
Disk scan : Yes
Built-in FTP server : Yes
Password authentication : Yes
Type : NAS
Buzzer : Yes
Remotely operated : Yes
Noise level : 21.4 dB
Power cables quantity : 1
Cables included : LAN (RJ-45), AC
Number of screws : 24
Server operating systems supported : Windows Server 2012 R2, Windows Server 2016, Windows Server 2012, Windows Server 2008 R2, Windows Server 2019
Operating system installed : QNAP Turbo System
Windows operating systems supported : Windows 8, Windows 10, Windows 7
Linux operating systems supported : Yes
Mac operating systems supported : Mac OS X 10.10 Yosemite
RAID levels : 10, 6, JBOD, 0, 1, 5
RAID rebuild : Yes
Supported storage drive interfaces : M.2, Serial ATA, Serial ATA II, Serial ATA III
Online RAID expansion : Yes
Storage drives installed : No
Number of system drives installed : 1
Hot-swap drive bays : Yes
Online RAID migration : Yes
System drive capacity : 5 GB
Installed storage drive type : No
RAID support : Yes
Supported storage drive types : HDD & SSD
Number of M.2 (M & B) slots : 2
Total installed storage capacity : 0 TB
Storage drive sizes supported : 2.5, 3.5", M.2
Number of storage drives supported : 4
Storage drive interface : Serial ATA III
Storage drive capacity : 0 GB
Concurrent connections : 2000
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity : 3
USB port : Yes
Ethernet LAN (RJ-45) ports : 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity : 1
PCI Express x4 (Gen 3.x) slots : 2
Harmonized System (HS) code : 84714100
