Description
Processor threads : 8
Processor cores : 4
Number of processors supported : 1
Processor frequency : 2.2 GHz
Processor manufacturer : AMD
Processor model : V1500B
Processor family : Ryzen Embedded
Processor generation : AMD Ryzen Embedded V1000 Series
Internal memory type : DDR4
Memory slots : 2
Maximum RAM supported : 64 GB
ECC : Yes
Memory form factor : SO-DIMM
Internal memory : 8 GB
Flash memory : 5000 MB
Housing material : Metal
Fan diameter 2 : 9.2 cm
Cable lock slot type : Kensington
Product colour : Black
Chassis type : Tower
LED indicators : HDD, Status, Power, LAN, SSD, USB
Fan diameter : 6 cm
Number of fans : 3 fan(s)
Cooling type : Active
Cable lock slot : Yes
Number of power supply units : 1
Power supply location : Built-in
Power consumption (sleep) : 21.891 W
Power supply unit (PSU) capacity : 250 W
AC input voltage : 100 – 240 V
Power consumption (typical) : 45.898 W
AC input frequency : 50 – 60 Hz
Operating relative humidity (H-H) : 5 – 95%
Operating temperature (T-T) : 0 – 40 °C
Storage temperature (T-T) : -20 – 70 °C
Depth : 280.8 mm
Width : 264.3 mm
Height : 188.2 mm
Weight : 5.78 kg
Jumbo frames support : Yes
Ethernet LAN data rates : 2500, 100, 1000 Mbit/s, 5000 Mbit/s
Ethernet LAN : Yes
Wake-on-LAN ready : Yes
iSCSI support : Yes
Dynamic DNS (DDNS) : Yes
DHCP server : Yes
Security algorithms : SSH, 256-bit AES, SSL/TLS, FIPS 140-2
Browser supported : Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox
Device class : Small & Medium Business
Snapshot : Yes
Backup features : Cloud, iSCSI LUN
Access Control List (ACL) : Yes
Built-in FTP server : Yes
Password authentication : Yes
Buzzer : Yes
Reset button : Yes
Hot spare : Yes
Backup function : Yes
On/off switch : Yes
Type : NAS
S.M.A.R.T. support : Yes
Noise level : 20.3 dB
Remotely operated : Yes
Windows operating systems supported : Windows 10, Windows 8, Windows 11, Windows 7
Mac operating systems supported : Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 10.10 Yosemite, Mac OS X 10.12 Sierra, Mac OS X 10.15.3 Catalina, Mac OS X 10.14 Mojave, Mac OS X 10.8 Mountain Lion, Mac OS X 10.7 Lion, Mac OS X 10.11 El Capitan, Mac OS X 10.6 Snow Leopard, Mac OS X 10.4 Tiger, Mac OS X 10.2 Jaguar, Mac OS X 10.5 Leopard, Mac OS X 10.13 High Sierra, Mac OS X 10.9 Mavericks, Mac OS X 10.3 Panther
Server operating systems supported : Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2012, Windows Server 2008 R2
Other operating systems supported : Solaris 10
Linux operating systems supported : CentOS 7.0, Ubuntu 14.04
Operating system version : 5.0.0
Operating system installed : QNAP Turbo System
RAID levels : JBOD, 1, 10, 0, 6, 50, 5
Supported file systems : FAT32, ext3, NTFS, ext4, HFS+
Installed storage drive type : No
Hot-swap drive bays : Yes
RAID support : Yes
Total installed storage capacity : 0 TB
Supported storage drive interfaces : M.2, Serial ATA II, Serial ATA III
Supported storage drive types : HDD & SSD
Storage drive interface : M.2, Serial ATA II, Serial ATA III
System drive capacity : 5 GB
RAID rebuild : Yes
Storage drives installed : No
Storage drive sizes supported : 2.5, M.2, 3.5"
Number of system drives installed : 1
Number of M.2 (M & B) slots : 2
Number of storage drives supported : 8
Storage drive capacity : 0 GB
Ethernet LAN (RJ-45) ports : 2
USB port : Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity : 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity : 1
Concurrent connections : 2000
Harmonized System (HS) code : 84714100
